LM2902SR
Standard (General Purpose) Amplifier 4 Circuit SOP-14
SOP-14ROHS CompliantActive
Low-cost, high-voltage operational amplifiers
- Manufacturer
- COSINE
- Manufacturer part #
- LM2902SR
- Store part #
- C42437070
- Package / case
- SOP-14
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,755 in stock
#C42437070
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹12.52 | ₹62.60 |
| 50+ | ₹10.25 | ₹512.50 |
| 150+ | ₹9.13 | ₹1,369.50 |
| 500+ | ₹8.28 | ₹4,140.00 |
| 3,000+ | ₹7.61 | ₹22,830.00 |
| 6,000+ | ₹7.26 | ₹43,560.00 |
5 × ₹12.52
₹62.60
excl. GST
₹73.87 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
LM2902SR
₹62.60 for 5 + GST
Specifications
- Output Current
- 40mA
- Number of Channels
- 4
- Vos - Input Offset Voltage
- 2mV
- Slew Rate
- 350V/ms
- Input Offset Current(Ios)
- 3nA
- Operating Temperature
- -40℃~+85℃
- Common Mode Rejection Ratio(CMRR)
- 90dB
- Ib - Input Bias Current
- 45nA
- Input Offset Voltage Drift(Vos TC)
- 7uV/℃
- Gain Bandwidth Product
- 1MHz
- Quiescent Current
- 250uA
- Features
- Built-in compensation
- Dual Supply
- -18V~-1.5V;1.5V~18V
- Single Supply
- 3V~36V
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.277 g
Overview
The LM2904 (dual) and LM2902 (quad) are low-power, low cost operational amplifiers (op amps) operated on 3V to 36V supplies. Despite their wide supply range, the LM2904/2902 family provides excellent overall performance and versatility. They have high differential input voltage capability. The common-mode input voltage range includes ground, enabling direct sensing near ground. The LM2904/2902 family is unity gain stable and has a gain bandwidth product of 1.0MHz (typical). They provide high CMRR and PSRR performance and can operate from a single supply voltage as well as dual supply voltages. The LM2904/2902 family can be designed into a wide range of applications at an economical price without sacrificing basic performance.
Applications
- Power Supplies and Mobile Chargers
- Motor Control
- AC Inverters
- White Goods
- Battery or Solar Powered Systems
Key features
- Wide Supply Range of 3V ~ 36V
- Large DC Voltage Gain: 100dB
- Quiescent Current per Amplifier: 250μA
- Gain Bandwidth Product: 1.0 MHz
- Slew Rate: 0.35V/µs
- Unity Gain Stable
- Input Common-mode Voltage Range Includes negative Rails
- Differential Input Voltage Range Equal to the Power Supply Voltage
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | LM324SR#C22447444COSINE · SOP-14 | COSINE | SOP-14 | 3,115 | ₹15.61 · 3,115 in stock | View |
 | COS324HV#C22447445COSINE · SOP-14 | COSINE | SOP-14 | 1,935 | ₹13.93 · 1,935 in stock | View |
 | LMV324SR#C22391246COSINE · SOP-14 | COSINE | SOP-14 | 970 | ₹20.15 · 970 in stock | View |
 | COS324SR#C693061COSINE · SOP-14 | COSINE | SOP-14 | 1,640 | ₹22.94 · 1,640 in stock | View |
 | COS2254SR#C2979744COSINE · SOP-14 | COSINE | SOP-14 | 262 | ₹71.28 · 262 in stock | View |
