LM34927MRX/NOPB
Buck Switching Regulator IC Adjustable 1 Output 600mA SO-PowerPAD-8
SO-PowerPAD-8ROHS3 CompliantActive
Integrated secondary-side bias regulator for isolated DC/DC converters
- Manufacturer
- TI
- Manufacturer part #
- LM34927MRX/NOPB
- Store part #
- C2071501
- Package / case
- SO-PowerPAD-8
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
7 in stock
#C2071501
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹366.70 | ₹366.70 |
| 10+ | ₹307.95 | ₹3,079.50 |
| 30+ | ₹271.03 | ₹8,130.90 |
| 100+ | ₹233.46 | ₹23,346.00 |
| 500+ | ₹216.39 | ₹1,08,195.00 |
| 1,000+ | ₹209.05 | ₹2,09,050.00 |
1 × ₹366.70
₹366.70
excl. GST
₹432.71 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
LM34927MRX/NOPB
₹366.70 for 1 + GST
Specifications
- Operating Temperature
- -40℃~+125℃@(TA)
- Frequency - Switching
- 1MHz
- Function
- Step-down type
- Number of Outputs
- 1
- Features
- Adjustable current limiting;Cycle-by-cycle current limiting;Adjustable soft-start;Built-in LDO regulator;Overcurrent Protection
- Output Type
- Adjustable
- Topology
- Buck
- Operating Voltage
- 7.5V~100V
- Switch tube (built-in/external)
- Built-in
- Output Current
- 600mA
- Quiescent Current
- 1.75mA
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.001 g
Overview
The LM34927 regulator integrates all the features necessary to implement a low-cost, high-efficiency isolated bias regulator. This high-voltage regulator incorporates two 100V N-channel MOSFET switches — a high-side buck switch and a low-side synchronous switch. The constant on-time (COT) control scheme employed by the LM34927 eliminates loop compensation while delivering excellent transient response. The regulator's on-time is inversely proportional to the input voltage, a characteristic that keeps the switching frequency relatively constant. An integrated sensing circuit performs intelligent peak current limiting. Additional features include a programmable input undervoltage comparator to inhibit operation under low-voltage conditions. Protection features include thermal shutdown and VCC undervoltage lockout (UVLO). The LM34927 is available in WSON-8 and SO PowerPAD-8 plastic packages.
Applications
- Isolated telecom bias supply
- Isolated automotive and industrial electronic components
Key features
- 7.5V to 100V wide input voltage range
- Integrated 600mA high-side and low-side switches
- No Schottky diode required
- Constant on-time control
- No loop compensation required
- Ultra-fast transient response
- Near-constant operating frequency
- Intelligent peak current limiting
- Adjustable output voltage (1.225V reference voltage)
- 2% feedback reference voltage accuracy
- Frequency adjustable up to 1MHz
- Adjustable UVLO
- Remote shutdown
- Thermal shutdown
- Package: 8-pin WSON, 8-pin SO PowerPAD
