TIDatasheet (PDF)
LMV358QDR
40mA 2 1.7mV 1V/us 63dB 11nA 210uA 1MHz Rail-to-rail output SOIC-8 Instrumentation, Op Amps, Buffer Amps RoHS
SOIC-8ROHS3 CompliantActive
Low-Voltage Rail-to-Rail Output Operational Amplifier
- Manufacturer
- TI
- Manufacturer part #
- LMV358QDR
- Store part #
- C2058604
- Package / case
- SOIC-8
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
20 in stock
#C2058604
Stock & price checked 9 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹102.06 | ₹102.06 |
| 10+ | ₹81.47 | ₹814.70 |
| 30+ | ₹71.07 | ₹2,132.10 |
| 100+ | ₹60.90 | ₹6,090.00 |
| 500+ | ₹54.61 | ₹27,305.00 |
| 1,000+ | ₹51.57 | ₹51,570.00 |
1 × ₹102.06
₹102.06
excl. GST
₹120.43 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
LMV358QDR
₹102.06 for 1 + GST
Specifications
- Output Current
- 40mA
- Number of Channels
- 2
- Vos - Input Offset Voltage
- 1.7mV
- Slew Rate
- 1V/us
- Input Offset Current(Ios)
- 5nA
- Operating Temperature
- -40℃~+125℃
- Common Mode Rejection Ratio(CMRR)
- 63dB
- Ib - Input Bias Current
- 11nA
- Input Offset Voltage Drift(Vos TC)
- 5uV/℃
- Quiescent Current
- 210uA
- Gain Bandwidth Product
- 1MHz
- Input Voltage Noise Density
- 39nV/√Hz@1kHz
- Rail to Rail
- Rail-to-rail output
- Single Supply
- 2.7V~5.5V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.18 g
Overview
The LMV321, LMV358, and LMV324 devices are single, dual, and quad low-voltage (2.7 V to 5.5 V) operational amplifiers with rail-to-rail output swing. These devices are cost-effective solutions for applications where low-voltage operation, space saving, and low cost are needed. These amplifiers are designed specifically for low-voltage (2.7 V to 5 V) operation, with performance specifications meeting or exceeding the LM358 and LM324 devices that operate from 5 V to 30 V. With package sizes down to one-half the size of the DBV (SOT-23) package, these devices can be used for a variety of applications.
Applications
- Desktop PCs
- HVAC: heating, ventilating, and air conditioning
- Motor control: AC induction
- Netbooks
- Portable media players
- Power: telecom DC/DC module: digital
- Professional audio mixers
- Refrigerators
- Washing machines: high-end and low-end
Key features
- 2.7 V and 5-V performance
- -40°C to +125°C operation
- No crossover distortion
- Low supply current LMV321: 130 μA (typical) LMV358: 210 μA (typical) LMV324: 410 μA (typical)
- Rail-to-rail output swing
- ESD protection exceeds JESD 22 – 2000-V human-body model 1000-V charged-device model
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | XLV358D#C707067XINLUDA · SOP-8 | XINLUDA | SOP-8 | 2,050 | ₹10.41 · 2,050 in stock | View |
 | LMV358SG-13#C150507DIODES · SOIC-8 | DIODES | SOIC-8 | 752 | ₹69.33 · 752 in stock | View |
 | LMV358Q1MAX/NOPB#C202283TI · SOIC-8 | TI | SOIC-8 | 1,847 | ₹141.24 · 1,847 in stock | View |
 | LMV358MX/NOPB#C7983TI · SOIC-8 | TI | SOIC-8 | 4,292 | ₹80.93 · 4,292 in stock | View |
 | LMV358IDR#C63813TI · SOIC-8 | TI | SOIC-8 | 1,84,450 | ₹30.34 · 1,84,450 in stock | View |
