DIODESDatasheet (PDF)
LSP5526-S8A
340kHz Step-down type Adjustable 2A 925mV~18V SOP-8 Voltage Regulators - DC DC Switching Regulators RoHS
SOP-8ROHS3 CompliantActive
2A Wide Input Range Synchronous Buck Converter
- Manufacturer
- DIODES
- Manufacturer part #
- LSP5526-S8A
- Store part #
- C3037772
- Package / case
- SOP-8
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
143 in stock
#C3037772
Stock & price checked 9 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹56.47 | ₹56.47 |
| 10+ | ₹44.92 | ₹449.20 |
| 30+ | ₹39.90 | ₹1,197.00 |
| 100+ | ₹33.80 | ₹3,380.00 |
| 500+ | ₹30.96 | ₹15,480.00 |
| 1,000+ | ₹29.44 | ₹29,440.00 |
1 × ₹56.47
₹56.47
excl. GST
₹66.63 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
LSP5526-S8A
₹56.47 for 1 + GST
Specifications
- Operating Temperature
- -20℃~+125℃
- Frequency - Switching
- 340kHz
- Function
- Step-down type
- Number of Outputs
- 1
- Features
- Cycle-by-cycle current limiting;Adjustable soft-start;Output discharge;External compensation
- Output Type
- Adjustable
- Topology
- Buck
- Operating Voltage
- 4.5V~23V
- Switch tube (built-in/external)
- Built-in
- Output Current
- 2A
- Output Voltage
- 925mV~18V
- Quiescent Current
- 1.3mA
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.158 g
Overview
The DIODES™ LSP5526 is a monolithic synchronous buck regulator. The device integrates 95mΩ MOSFETS that provide 2A continuous load current over a wide operating input voltage of 4.5V to 23V. Current mode control provides fast transient response and cycle-by-cycle current limit. An adjustable soft-start prevents inrush current at turn on.
Applications
- Distributed power systems
- Networking systems
- FPGA, DSP, ASIC power supplies
- Green electronics / appliances
- Notebook computers
Key features
- 2A Output Current
- Wide 4.5V to 23V Operating Input Range
- Integrated Power MOSFET Switches
- Output Adjustable from 0.925V to 18V
- Up to 96% Efficiency
- Programmable Soft-Start
- Stable with Low ESR Ceramic Output Capacitors
- Fixed 340KHZ Frequency
- Cycle by Cycle Over Current Protection
- Input Under Voltage Lockout
- Package: SOP-8L
- Totally Lead-free & Fully RoHS Compliant
- Halogen and Antimony Free. “Green” Device
