ADI

LT8613IUDE#TRPBF

200kHz~2.2MHz Step-down type Adjustable 6A QFN-28-EP(3x6) Voltage Regulators - DC DC Switching Regulators RoHS

QFN-28-EP(3x6)ROHS3 CompliantActive

42V, 6A Synchronous Step-Down Regulator with Current Sense and 3uA Quiescent Current

Manufacturer: ADI
Manufacturer part #: LT8613IUDE#TRPBF
Store part #: C674064
Package / case: QFN-28-EP(3x6)
Category: Voltage Regulators - DC DC Switching Regulators
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

111 in stock

#C674064

Stock & price checked 3 days ago

Quantity	Unit price	Pack price
1+	₹2,662.30	₹2,662.30
10+	₹2,544.70	₹25,447.00
30+	₹2,340.86	₹70,225.80
100+	₹2,162.95	₹2,16,295.00

Quantity (min 1)

1 × ₹2,662.30

₹2,662.30

excl. GST

₹3,141.51 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 2,500 per reel

LT8613IUDE#TRPBF

₹2,662.30 for 1 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Operating Temperature: -40℃~+125℃@(TJ)
Frequency - Switching: 200kHz~2.2MHz
Function: Step-down type
Number of Outputs: 1
Features: Adjustable current limiting;Adjustable soft-start;Frequency synchronization;Light load efficient mode;Operating status indication;Overcurrent Protection
Output Type: Adjustable
Topology: Buck
Operating Voltage: 3.4V~42V
Switch tube (built-in/external): Built-in
Output Current: 6A
Quiescent Current: 3uA

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 2,500 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.33 g

Overview

The LT8613 is a compact, high efficiency, high speed synchronous monolithic step-down switching regulator that consumes only 3µA of quiescent current. Top and bottom power switches are included with all necessary circuitry to minimize the need for external components. The built-in current sense amplifier with monitor and control pins allows accurate input or output current regulation and limiting. Low ripple Burst Mode operation enables high efficiency down to very low output currents while keeping the output ripple below 10mVP-P. A SYNC pin allows synchronization to an external clock. Internal compensation with peak current mode topology allows the use of small inductors and results in fast transient response and good loop stability. The EN/UV pin has an accurate 1V threshold and can be used to program VIN undervoltage lockout or to shut down the LT8613 reducing the input supply current to 1µA. A capacitor on the TR/SS pin programs the output voltage ramp rate during start-up. The PG flag signals when VOUT is within ±9% of the programmed output voltage as well as fault conditions. The LT8613 is available in a small 28-lead 3mm × 6mm QFN package with exposed pad for low thermal resistance.

Applications

Automotive and Industrial Supplies
General Purpose Step-Down CCCV Power Supplies

Key features

Rail-to-Rail Current Sense Amplifier with Monitor
Wide Input Voltage Range: 3.4V to 42V
Ultralow Quiescent Current Burst Mode Operation: 3µA I0 Regulating 12VIN to 3.3VOUT Output Ripple < 10mVP-P
High Efficiency Synchronous Operation: 95% Efficiency at 3A, 5VOUT from 12VIN; 94% Efficiency at 3A, 3.3VOUT from 12VIN
Fast Minimum Switch-On Time: 40ns
Low Dropout Under All Conditions: 250mV at 3A
Allows Use of Small Inductors
Low EMI
Adjustable and Synchronizable: 200kHz to 2.2MHz
Current Mode Operation
Accurate 1V Enable Pin Threshold
Internal Compensation
Output Soft-Start and Tracking
Small Thermally Enhanced 3mm × 6mm 28-Lead QFN Package
