onsemiDatasheet (PDF)
MBR745G
Diode 45V 7.5A Through Hole TO-220AC-2
TO-220AC-2ROHS3 CompliantActive
DIODE SCHOTTKY 45V TO-220AC-2
- Manufacturer
- onsemi
- Manufacturer part #
- MBR745G
- Store part #
- C150057
- Package / case
- TO-220AC-2
- Category
- Single Diodes
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
135 in stock
#C150057
Stock & price checked 10 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹174.00 | ₹174.00 |
| 10+ | ₹147.34 | ₹1,473.40 |
| 50+ | ₹134.13 | ₹6,706.50 |
| 100+ | ₹120.91 | ₹12,091.00 |
| 500+ | ₹113.10 | ₹56,550.00 |
| 1,000+ | ₹108.99 | ₹1,08,990.00 |
1 × ₹174.00
₹174.00
excl. GST
₹205.32 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 50 per tube
MBR745G
₹174.00 for 1 + GST
Specifications
- Diode Configuration
- 1 Independent
- Operating Junction Temperature Range
- -65℃~+175℃
- Voltage - DC Reverse (Vr) (Max)
- 45V
- Voltage - Forward(Vf@If)
- 840mV@15A
- Reverse Leakage Current (Ir)
- 100uA@45V
- Non-Repetitive Peak Forward Surge Current
- 150A
- Current - Rectified
- 7.5A
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tube-packed
- Standard pack
- 50 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 2.76 g
Overview
Applications
- Power Supply
- Output Rectification
- Power Management
- Instrumentation
Key features
- Low Forward Voltage
- Low Power Loss/High Efficiency
- High Surge Capacity
- 175℃ Operating Junction Temperature
- Pb-Free Packages are Available
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | MBR1060G#C89052onsemi · TO-220AC-2 | onsemi | TO-220AC-2 | 41 | ₹162.76 · 41 in stock | View |
| MBR10100G#C26327onsemi · TO-220AC-2 | onsemi | TO-220AC-2 | 88 | ₹167.33 · 88 in stock | View | |
 | MBR10100-E3/4W#C5767963VISHAY · TO-220AC | VISHAY | TO-220AC | 6 | ₹143.43 · 6 in stock | View |
 | MBR10200L#C5375274XCH · TO-220AC | XCH | TO-220AC | 100 | ₹33.86 · 100 in stock | View |
 | STPS745D#C283262ST · TO-220AC | ST | TO-220AC | 6 | ₹77.71 · 6 in stock | View |
