MSRT8272GSP
Step-down type 500kHz Adjustable 925mV~5V 3A ESOP-8 Voltage Regulators - DC DC Switching Regulators
ESOP-8RoHSActive
- Manufacturer
- MSKSEMI
- Manufacturer part #
- MSRT8272GSP
- Store part #
- C49375231
- Package / case
- ESOP-8
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
895 in stock
#C49375231
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹40.68 | ₹203.40 |
| 50+ | ₹31.95 | ₹1,597.50 |
| 150+ | ₹28.21 | ₹4,231.50 |
| 500+ | ₹23.54 | ₹11,770.00 |
| 3,000+ | ₹21.45 | ₹64,350.00 |
| 6,000+ | ₹20.20 | ₹1,21,200.00 |
5 × ₹40.68
₹203.40
excl. GST
₹240.01 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
MSRT8272GSP
₹203.40 for 5 + GST
Specifications
- Operating Temperature
- -40℃~+85℃
- Number of Outputs
- 1
- Function
- Step-down type
- Frequency - Switching
- 500kHz
- Features
- Cycle-by-cycle current limiting;Hiccup current limiting;Overcurrent Protection;Light load efficient mode
- Output Type
- Adjustable
- Topology
- Buck
- Operating Voltage
- 4V~18V
- Switch tube (built-in/external)
- Built-in
- Output Voltage
- 925mV~5V
- Output Current
- 3A
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.113 g
Overview
MSRT8272GSP is a high-frequency, synchronous rectified, step-down switching mode converter with integrated power MOSFETs. It delivers a compact solution over a wide input supply range, capable of 4A peak output current with excellent load and line regulation. The device requires a minimal number of readily available external components and is offered in a space-saving ESOP8 package.
Applications
- Digital set-top boxes
- Tablets
- Flat-panel TVs and monitors
- Wi-Fi routers
- Digital video recorders
Key features
- 4V to 18V wide input voltage range
- 3A continuous output current
- 500kHz switching frequency
- Short-circuit protection with hiccup mode
- Built-in overcurrent limiting
- Built-in overvoltage protection
- Internal power-saving mode (PFM/PWM)
- Internal soft-start
- 70mΩ/50mΩ low RDS(ON) internal power MOSFET
- Output voltage adjustable from 0.925V
- No Schottky diode required
- Integrated internal compensation
- Thermal shutdown
- ESOP8 package
- -40℃ to +85℃ temperature range
