onsemiDatasheet (PDF)
NCV8165ML330TCG
3.3V Positive Fixed TDFN-8-EP(3x3) Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
TDFN-8-EP(3x3)ROHS3 CompliantActive
- Manufacturer
- onsemi
- Manufacturer part #
- NCV8165ML330TCG
- Store part #
- C893149
- Package / case
- TDFN-8-EP(3x3)
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,946 in stock
#C893149
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹150.86 | ₹150.86 |
| 10+ | ₹123.40 | ₹1,234.00 |
| 30+ | ₹108.35 | ₹3,250.50 |
| 100+ | ₹91.13 | ₹9,113.00 |
| 500+ | ₹83.72 | ₹41,860.00 |
| 1,000+ | ₹80.23 | ₹80,230.00 |
1 × ₹150.86
₹150.86
excl. GST
₹178.01 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
NCV8165ML330TCG
₹150.86 for 1 + GST
Specifications
- Output Voltage
- 3.3V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+125℃@(Tj)
- Supply Current (Iq)
- 9.7uA
- Output Configuration
- Positive
- Operating Voltage
- 5.5V
- Output Current
- 500mA
- Output Type
- Fixed
- Features
- Enable control;Output discharge;Short Circuit Protection;Over Current Protection;Thermal shutdown
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.148 g
Overview
The NCV8165 is a linear regulator capable of supplying 500 mA output current. Designed to meet the requirements of RF and analog circuits, the NCV8165 device provides low noise, high PSRR, low quiescent current, and very good load/line transients. The device is designed to work with a 1 μF input and a 1 μF output ceramic capacitor. It is available in DFNW8 3 mm×3 mm package with wettable flanks.
Applications
- Battery−powered Equipment
- Wireless LAN Devices
- Smartphones, Tablets
- Cameras, DVRs, STB and Camcorders
Key features
- Operating Input Voltage Range: 1.9 V to 5.5 V
- Available in Fixed Voltage Option: 1.8 V to 5.2 V
- ±2% Accuracy Over Load/Temperature
- Ultra Low Quiescent Current Typ. 12 μA
- Standby Current: Typ. 0.1 μA
- Very Low Dropout: 190 mV at 500 mA
- Ultra High PSRR: Typ. 85 dB at 20 mA, f = 1 kHz
- Ultra Low Noise: 8.5 μVRMS
- Stable with a 1 μF Small Case Size Ceramic Capacitors
- Available in −DFNW8 0.65P, 3 mm × 3 mm × 0.9 mm Package
- NCV Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC−Q100 Qualified and PPAP Capable
- These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS Compliant
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | TPS73633DRBR#C106192TI · VSON-8-EP(3x3) | TI | VSON-8-EP(3x3) | 13 | ₹402.59 · 13 in stock | View |
 | TPS74533PQWDRBRQ1#C3746737TI · SON-8(3x3) | TI | SON-8(3x3) | 399 | ₹134.87 · 399 in stock | View |
 | TPS73533DRBT#C115872TI · VSON-8-EP(3x3) | TI | VSON-8-EP(3x3) | 361 | ₹118.61 · 361 in stock | View |
 | TPS73533QDRBRQ1#C2867192TI · SON-8(3x3) | TI | SON-8(3x3) | 1,649 | ₹162.62 · 1,649 in stock | View |
 | TPS73533DRBR#C388480TI · SON-8(3x3) | TI | SON-8(3x3) | 4,388 | ₹161.19 · 4,388 in stock | View |
