onsemiDatasheet (PDF)
NTMFSC004N08MC
N-Channel 80V 136A 127W Surface Mount DFN-8(4.9x5.8)
DFN-8(5.1x6.2)ROHS3 CompliantActive
MOSFET N-CH 80V 136A DFN-8(4.9x5.8)
- Manufacturer
- onsemi
- Manufacturer part #
- NTMFSC004N08MC
- Store part #
- C894040
- Package / case
- DFN-8(5.1x6.2)
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
16 in stock
#C894040
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹280.75 | ₹280.75 |
| 10+ | ₹274.23 | ₹2,742.30 |
| 30+ | ₹269.89 | ₹8,096.70 |
| 100+ | ₹265.33 | ₹26,533.00 |
1 × ₹280.75
₹280.75
excl. GST
₹331.29 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
NTMFSC004N08MC
₹280.75 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 950pF
- Ciss-Input Capacitance
- 2.98nF
- Pd - Power Dissipation
- 127W
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 80V
- Current - Continuous Drain(Id)
- 136A
- Reverse Transfer Capacitance (Crss)
- 50pF
- RDS(on)
- 4mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 27.8nC@6V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 4V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.3 g
Overview
Applications
- Orring FET/Load Switching
- Synchronous Rectifier
- DC−DC Conversion
Key features
- Advanced Dual−Sided Cooled Packaging
- Ultra Low RDS(on) to Minimize Conduction Losses
- MSL1 Robust Packaging Design
- These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS Compliant
