NVD3055-094T4G-VF01
N-Channel 60V 12A 1.5W Surface Mount DPAK
DPAKROHS3 CompliantActive
MOSFET N-CH 60V 12A DPAK
- Manufacturer
- onsemi
- Manufacturer part #
- NVD3055-094T4G-VF01
- Store part #
- C604530
- Package / case
- DPAK
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
125 in stock
#C604530
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹330.15 | ₹330.15 |
| 10+ | ₹292.11 | ₹2,921.10 |
| 30+ | ₹268.25 | ₹8,047.50 |
| 100+ | ₹243.75 | ₹24,375.00 |
| 500+ | ₹232.78 | ₹1,16,390.00 |
| 1,000+ | ₹228.06 | ₹2,28,060.00 |
1 × ₹330.15
₹330.15
excl. GST
₹389.58 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
NVD3055-094T4G-VF01
₹330.15 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 1.3nF
- Ciss-Input Capacitance
- 450pF
- Pd - Power Dissipation
- 1.5W
- Operating Temperature
- -40℃~+175℃
- Drain to Source Voltage
- 60V
- Current - Continuous Drain(Id)
- 12A
- Reverse Transfer Capacitance (Crss)
- 200pF
- RDS(on)
- 94mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 20nC@10V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 4V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.437 g
Overview
The NVH820S75L4SPB is a power module from the VE−Trac Direct family of highly integrated power modules with industry standard footprints for Hybrid (HEV) and Electric Vehicle (EV) traction inverter application. The module integrates six Field Stop 4 (FS4) 750 V Narrow Mesa IGBTs in a 6−pack configuration, which excels in providing high current density, while offering robust short circuit protection and increased blocking voltage. Additionally, FS4 750 V Narrow Mesa IGBTs show low power losses during lighter loads, which helps to improve overall system efficiency in automotive applications. For assembly ease and reliability, a new generation of press−fit pins are integrated into the power module signal terminals. In addition, the power module has an optimized pin−fin heatsink in the baseplate.
Applications
- Hybrid and Electric Vehicle Traction Inverter
- High Power Converters
Key features
- Direct Cooling w/ Integrated Pin−fin Heatsink
- Ultra−low Stray Inductance
- Tjmax = 175°C Continuous Operation
- Low VCESAT and Switching Losses
- Automotive Grade FS4 750 V Narrow Mesa IGBT
- Fast Recovery Diode Chip Technologies
- 4.2 kV Isolated DBC Substrate
- Easy to Integrate 6−pack Topology
- This Device is Pb −Free and is RoHS Compliant
