NVD5C464NT4G
N-Channel 40V 59A 40W Surface Mount DPAK
DPAKROHS3 CompliantActive
MOSFET N-CH 40V 59A DPAK
- Manufacturer
- onsemi
- Manufacturer part #
- NVD5C464NT4G
- Store part #
- C887737
- Package / case
- DPAK
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
175 in stock
#C887737
Stock & price checked 10 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹204.32 | ₹204.32 |
| 10+ | ₹170.96 | ₹1,709.60 |
| 30+ | ₹152.54 | ₹4,576.20 |
| 100+ | ₹131.74 | ₹13,174.00 |
| 500+ | ₹122.43 | ₹61,215.00 |
| 1,000+ | ₹118.32 | ₹1,18,320.00 |
1 × ₹204.32
₹204.32
excl. GST
₹241.10 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
NVD5C464NT4G
₹204.32 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 580pF
- Ciss-Input Capacitance
- 1.2nF
- Pd - Power Dissipation
- 40W
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 40V
- Current - Continuous Drain(Id)
- 59A
- Reverse Transfer Capacitance (Crss)
- 32pF
- RDS(on)
- 5.8mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 20nC@10V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 4V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.42 g
Overview
Key features
- Low RDS(on) for minimized conduction losses
- Low QG and capacitance for minimized driving losses
- AEC-Q101 qualified, PPAP documentation available
- Lead-free, halogen-free/BFR-free, RoHS compliant
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SP40N06TH#C41355046Siliup · TO-252-2L | Siliup | TO-252-2L | 100 | ₹17.21 · 100 in stock | View |
 | KCD3008A#C2839422KIA Semicon Tech · TO-252 | KIA Semicon Tech | TO-252 | 1,155 | ₹58.66 · 1,155 in stock | View |
 | STD95N4F3#C411389ST · DPAK | ST | DPAK | 2 | ₹175.35 · 2 in stock | View |
 | DOD70N04T#C48542674DOINGTER · TO-252 | DOINGTER | TO-252 | 2,130 | ₹26.46 · 2,130 in stock | View |
 | MU6004D#C47361192MIRACLE POWER · TO-252 | MIRACLE POWER | TO-252 | 2,160 | ₹21.68 · 2,160 in stock | View |
