onsemiDatasheet (PDF)
NVMFS5C628NT1G
N-Channel 60V 150A 110W Surface Mount SO-8FL
SO-8FLROHS3 CompliantActive
MOSFET N-CH 60V 150A SO-8FL
- Manufacturer
- onsemi
- Manufacturer part #
- NVMFS5C628NT1G
- Store part #
- C900448
- Package / case
- SO-8FL
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
20 in stock
#C900448
Stock & price checked 4 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹322.26 | ₹322.26 |
| 10+ | ₹314.44 | ₹3,144.40 |
| 30+ | ₹309.00 | ₹9,270.00 |
| 100+ | ₹303.58 | ₹30,358.00 |
1 × ₹322.26
₹322.26
excl. GST
₹380.27 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 1,500 per reel
NVMFS5C628NT1G
₹322.26 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 1.68nF
- Ciss-Input Capacitance
- 2.63nF
- Pd - Power Dissipation
- 110W
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 60V
- Current - Continuous Drain(Id)
- 150A
- Reverse Transfer Capacitance (Crss)
- 13pF
- RDS(on)
- 2.3mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 34nC@10V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 4V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 1,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.363 g
Overview
Key features
- Small Footprint <5x6 mm> for Compact Design
- Low RDS(on) to Minimize Conduction Losses
- Low QG and Capacitance to Minimize Driver Losses
- NVMFS5C628NWF − Wettable Flank Option for Enhanced Optical Inspection
- AEC−Q101 Qualified and PPAP Capable
- These Devices are Pb−Free and are RoHS Compliant
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | NVMFS5C628NLAFT1G#C604608onsemi · SO-8FL | onsemi | SO-8FL | 4 | ₹1,021.82 · 4 in stock | View |
 | STL160N10F8#C28247598ST · PowerFLAT-8(5x6) | ST | PowerFLAT-8(5x6) | 7 | ₹764.76 · 7 in stock | View |
 | NTMFS3D0N08XT1G#C25428461onsemi · SO-8FL | onsemi | SO-8FL | 2 | ₹164.28 · 2 in stock | View |
 | NTMFS5C628NLT1G#C145537onsemi · SO-8FL | onsemi | SO-8FL | 7,717 | ₹102.10 · 7,717 in stock | View |
 | CMSA022N10#C52118384Cmos · DFN-8(5x6) | Cmos | DFN-8(5x6) | 3,939 | ₹154.91 · 3,939 in stock | View |
