OB2358AP

45kHz~55kHz 600V Flyback DIP-8 AC DC Converters, Offline Switchers

DIP-8RoHSActive

Current Mode PWM Power Switch, Freq Shuffling

Manufacturer: OB
Manufacturer part #: OB2358AP
Store part #: C36607
Package / case: DIP-8
Category: AC DC Converters, Offline Switchers
Packaging: Tube-packed

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

9 in stock

#C36607

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
1+	₹60.36	₹60.36
10+	₹46.68	₹466.80
50+	₹41.04	₹2,052.00
100+	₹33.66	₹3,366.00
500+	₹30.61	₹15,305.00
1,000+	₹28.66	₹28,660.00

Quantity (min 1)

1 × ₹60.36

₹60.36

excl. GST

₹71.22 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 50 per tube

OB2358AP

₹60.36 for 1 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Operating Temperature: -20℃~+150℃
Frequency - Switching: 45kHz~55kHz
Voltage - Breakdown: 600V
Features: Light load efficient mode;EMI optimization (spread spectrum);Audio noise elimination;Leading edge blanking;Slope compensation;Under-voltage lockout;Soft-start;Over Voltage Protection;Under Voltage Protection;Over Current Protection
Topology: Flyback
Duty Cycle(Max): 90%
Working Mode: PWM Modulation
Feedback System: Secondary-Side Feedback

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Moisture sensitivity: MSL 3 (168 hours)
Packaging: Tube-packed
Standard pack: 50 / Tube
Sold per: Piece
Minimum order: 1
Unit weight: 0.8 g

Overview

OB2358 combines a dedicated current mode PWM controller with a high voltage power MOSFET. It is optimized for high performance, low standby power, and cost effective off-line flyback converter applications in sub 27W range. OB2358 offers complete protection coverage with automatic self-recovery feature including Cycle-byCycle current limiting (OCP), over load protection (OLP), VDD over voltage clamp and under voltage lockout (UVLO). Excellent EMI performance is achieved with On-Bright proprietary frequency shuffling technique together with soft switching control at the totem pole gate drive output. The tone energy at below 20KHZ is minimized in the design and audio noise is eliminated during operation. OB2358 is offered in DIP8 package.

Applications

Offline AC/DC flyback converter for
AC/DC adaptor
PDA power supplies
Digital Cameras and Camcorder Adaptor
VCR, SVR, STB, DVD&DVCD Player SMPS
Set-Top Box Power
Auxiliary Power Supply for PC and Server
Open-frame SMPS

Key features

Power on Soft Start Reducing MOSFET Vds Stress
Frequency shuffling for EMI
Extended Burst Mode Control For Improved Efficiency and Minimum Standby Power Design
Audio Noise Free Operation
