OCX

OC7141

LED Driver IC 1 Output Buck PWM Dimming 3A SOT-23-5

SOT-23-5ROHS CompliantActive

Linear step-down LED constant current driver with PWM dimming

Manufacturer: OCX
Manufacturer part #: OC7141
Store part #: C842737
Package / case: SOT-23-5
Category: LED Drivers ICs
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

4,855 in stock

#C842737

Stock & price checked 4 days ago

Quantity	Unit price	Pack price
5+	₹15.03	₹75.15
50+	₹12.11	₹605.50
150+	₹10.65	₹1,597.50
500+	₹9.55	₹4,775.00
3,000+	₹8.37	₹25,110.00
6,000+	₹7.92	₹47,520.00

Quantity (min 5, multiples of 5)

5 × ₹15.03

₹75.15

excl. GST

₹88.68 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 3,000 per reel

OC7141

₹75.15 for 5 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Features: Over-Temperature Protection (OTP)
Switch Tube (Built-In/External): External
Operating temperature: -20℃~+85℃
Topology: Buck
Number of Channels: 1
Output Current: 3A
Voltage - Input(DC): 2.5V~6V
Constant Current Accuracy: 4%

Packaging & compliance

RoHS: ROHS Compliant
Lifecycle: Active
Moisture sensitivity: MSL 1 (unlimited)
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.03 g

Overview

OC7141 is a linear buck LED constant-current driver with PWM dimming capability. Only one external resistor and one NMOS transistor are required to form a complete LED constant-current driving circuit. The output current can be adjusted by varying the external resistor, with an adjustable range of 10mA to 3000mA. OC7141 features built-in over-temperature protection to effectively protect the IC and MOSFET from damage due to overheating. OC7141 has very low quiescent current, with a typical value of 60μA. OC7141 supports PWM dimming, allowing LED current adjustment by applying a PWM signal to the DIM pin. OC7141 is available in a SOT-23-5 package.
