HGSEMI

OP37FDQ3/TR-HG

3.8mA 1 20uV 28nA 100dB DFN-8(3x3) Instrumentation, Op Amps, Buffer Amps

DFN-8(3x3)RoHSActive

Manufacturer: HGSEMI
Manufacturer part #: OP37FDQ3/TR-HG
Store part #: C52953083
Package / case: DFN-8(3x3)
Category: Instrumentation, Op Amps, Buffer Amps
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

1,000 in stock

#C52953083

Stock & price checked 12 days ago

Quantity	Unit price	Pack price
1+	₹179.85	₹179.85
10+	₹149.35	₹1,493.50
30+	₹132.67	₹3,980.10
100+	₹113.73	₹11,373.00
500+	₹105.48	₹52,740.00
1,000+	₹101.57	₹1,01,570.00

Quantity (min 1)

1 × ₹179.85

₹179.85

excl. GST

₹212.22 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 5,000 per reel

OP37FDQ3/TR-HG

₹179.85 for 1 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Quiescent Current: 3.8mA
Number of Channels: 1
Vos - Input Offset Voltage: 20uV
Input Offset Current(Ios): 8nA
Input Voltage Noise Density: 3.2nV/√Hz@1kHz
Operating Temperature: 0℃~+70℃
Ib - Input Bias Current: 28nA
Common Mode Rejection Ratio(CMRR): 100dB
Input Offset Voltage Drift(Vos TC): 1.8uV/℃

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Moisture sensitivity: MSL 3 (168 hours)
Packaging: Tape & Reel (TR)
Standard pack: 5,000 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.06 g

Overview

The OP37 is a high-precision op-amp with a maximum offset voltage of 100 μV and a gain of 200 V/mV. This makes it particularly well-suited for instrumentation and similar applications. With a wide input voltage range of ±13 V and a CMRR exceeding 100 dB, the OP37 maintains excellent linearity and gain accuracy even in high closed-loop gain circuits.
