TECH PUBLICDatasheet (PDF)
PDFB050150-SOD923
nan
SOD-923(0402)RoHSActive
5VWM 10VC SOD-923(0402)
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- PDFB050150-SOD923
- Store part #
- C2890114
- Package / case
- SOD-923(0402)
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,740 in stock
#C2890114
Stock & price checked 12 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 20+ | ₹5.01 | ₹100.20 |
| 200+ | ₹3.98 | ₹796.00 |
| 600+ | ₹3.40 | ₹2,040.00 |
| 2,000+ | ₹3.06 | ₹6,120.00 |
| 8,000+ | ₹2.35 | ₹18,800.00 |
| 16,000+ | ₹2.20 | ₹35,200.00 |
20 × ₹5.01
₹100.20
excl. GST
₹118.24 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 8,000 per reel
PDFB050150-SOD923
₹100.20 for 20 + GST
Specifications
- Clamping Voltage
- 10V
- Peak Pulse Current (Ipp)
- 8A@8/20us
- Peak Pulse Power Dissipation (Ppp)
- 80W@8/20us
- Voltage - Breakdown
- 8.4V
- Reverse Leakage Current (Ir)
- 80nA
- Reverse Stand-Off Voltage (Vrwm)
- 5V
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 8,000 / Reel
- Sold per
- Piece
- Minimum order
- 20 (multiples of 20)
- Unit weight
- 0.013 g
Overview
Applications
- SmartPhone and TabletPC
- TV and SetTopBox
- WearableDevices
- PDA
Key features
- Ultra low capacitance: 15pF typical
- Ultra low leakage: nA level
- Low operating voltage: ±5V
- Low clamping voltage
- 2-pin leadless package
- Complies with following standards:
- IEC 61000 - 4 - 2 (ESD) immunity test Air discharge: ±30kV Contact discharge: ±30kV
- IEC61000 - 4 - 5 (Lightning) 8A (8/20μs)
- RoHS Compliant Lead Finish: NiPdAu
