MDD(Microdiode Semiconductor)
2N7002KN-Channel 60V 300mA 300mW Surface Mount SOT-23
From
₹2.32
25,99,250 in stock
TECH PUBLICDatasheet (PDF)
PDMN66D0LDW
N-Channel 60V 0.3A 0.35W Surface Mount SOT-363
SOT-363RoHSActive
MOSFET N-CH 60V 0.3A SOT-363
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- PDMN66D0LDW
- Store part #
- C2912552
- Package / case
- SOT-363
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,540 in stock
#C2912552
Stock & price checked 10 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹7.05 | ₹70.50 |
| 100+ | ₹5.68 | ₹568.00 |
| 300+ | ₹4.99 | ₹1,497.00 |
| 3,000+ | ₹4.00 | ₹12,000.00 |
| 6,000+ | ₹3.59 | ₹21,540.00 |
| 9,000+ | ₹3.37 | ₹30,330.00 |
10 × ₹7.05
₹70.50
excl. GST
₹83.19 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
PDMN66D0LDW
₹70.50 for 10 + GST
Specifications
- Output Capacitance(Coss)
- 18pF
- Ciss-Input Capacitance
- 27pF
- Pd - Power Dissipation
- 350mW
- Drain to Source Voltage
- 60V
- Operating Temperature
- -55℃~+150℃
- Current - Continuous Drain(Id)
- 300mA
- Reverse Transfer Capacitance (Crss)
- 2pF
- RDS(on)
- 2.5Ω@4.5V
- Number
- 2 N-Channel
- Gate Charge(Qg)
- 3nC@10V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 2.5V
- Type
- N-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.028 g
Overview
Applications
- Notebook
- Load Switch
- Networking
- Hand-held Instruments
Key features
- Fast switching
- Green Device Available
- Suit for 1.5V Gate Drive Applications
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | 2N7002BKS#C2912543TECH PUBLIC · SOT-363 | TECH PUBLIC | SOT-363 | 43,100 | ₹5.95 · 43,100 in stock | View |
 | 2N7002KDW#C2912545TECH PUBLIC · SOT-363 | TECH PUBLIC | SOT-363 | 4,760 | ₹5.68 · 4,760 in stock | View |
 | NTJD5121NT1G#C2912549TECH PUBLIC · SOT-363 | TECH PUBLIC | SOT-363 | 4,400 | ₹7.14 · 4,400 in stock | View |
 | PUM6K31N#C2912551TECH PUBLIC · SOT-363 | TECH PUBLIC | SOT-363 | 2,970 | ₹7.24 · 2,970 in stock | View |
 | NTJD4001NT1G-TP#C48543206TECH PUBLIC · SOT-363 | TECH PUBLIC | SOT-363 | 1,430 | ₹5.86 · 1,430 in stock | View |
