JSMSEMI

PESD5V0S2BT,215-JSM

16V 20A@8/20us 300W@8/20us 7V Bidirectional 5V SOT-23 TVS Diodes RoHS

SOT-23ROHS CompliantActive

Manufacturer: JSMSEMI
Manufacturer part #: PESD5V0S2BT,215-JSM
Store part #: C53113839
Package / case: SOT-23
Category: TVS Diodes
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

1,640 in stock

#C53113839

Stock & price checked 8 days ago

Quantity	Unit price	Pack price
10+	₹7.63	₹76.30
100+	₹6.09	₹609.00
300+	₹5.31	₹1,593.00
3,000+	₹4.72	₹14,160.00
6,000+	₹4.26	₹25,560.00
9,000+	₹4.02	₹36,180.00

Quantity (min 10, multiples of 10)

10 × ₹7.63

₹76.30

excl. GST

₹90.03 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 3,000 per reel

PESD5V0S2BT,215-JSM

₹76.30 for 10 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Clamping Voltage: 16V
Operating Temperature: -55℃~+125℃
Peak Pulse Current (Ipp): 20A@8/20us
Peak Pulse Power Dissipation (Ppp): 300W@8/20us
Number of Channels: 2
Voltage - Breakdown: 7V
type: ESD
Polarity: Bidirectional
Reverse Leakage Current (Ir): 500nA
Reverse Stand-Off Voltage (Vrwm): 5V

Packaging & compliance

RoHS: ROHS Compliant
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 10 (multiples of 10)
Unit weight: 0.032 g

Overview

Applications

Data lines
ATM machines
Network
Power lines

Key features

300W peak pulse power (pulse duration tp = 8/20µs)
Bidirectional and unidirectional configurations
Solid-state silicon avalanche technology
Low clamping voltage
Low leakage current
Low capacitance (typical junction capacitance Cj = 120pF)
Protection for two data lines
Compliant with IEC61000-4-2: contact discharge ±30kV, air discharge ±30kV
Compliant with IEC61000-4-4 (EFT): 40A (5/50ns)
Compliant with IEC61000-4-5 (lightning surge): 20A (8/20µs)
SOT-23 package
Molding compound flammability rating: UL 94V-0
Packaging: tape and reel
RoHS/WEEE compliant
