DIODES

PI3DBS16222Q2ZLEX

3.3V 10GHz 4 2:2 TQFN-30(2.5x4.5) Analog Switches - Special Purpose RoHS

TQFN-30(2.5x4.5)ROHS3 CompliantActive

3.3V 20Gbps 4-Channel 2x2 Exchange Switch

Manufacturer: DIODES
Manufacturer part #: PI3DBS16222Q2ZLEX
Store part #: C5441276
Package / case: TQFN-30(2.5x4.5)
Category: Analog Switches - Special Purpose
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,686 in stock

#C5441276

Stock & price checked 4 days ago

Quantity	Unit price	Pack price
1+	₹474.92	₹474.92
10+	₹460.54	₹4,605.40
30+	₹451.96	₹13,558.80
100+	₹443.38	₹44,338.00
500+	₹439.30	₹2,19,650.00
1,000+	₹437.58	₹4,37,580.00

Quantity (min 1)

1 × ₹474.92

₹474.92

excl. GST

₹560.41 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 3,500 per reel

PI3DBS16222Q2ZLEX

₹474.92 for 1 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Voltage - Supply: 3.3V
-3dB Bandwidth: 10GHz
Number of Channels: 4
Switch Circuit: 2:2
Operating Temperature: -40℃~+105℃
Features: Bidirectional analog channel

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
Moisture sensitivity: MSL 1 (unlimited)
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 3,500 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.112 g

Overview

The PI3DBS16222Q is an automotive-qualified differential exchange switch featuring pass-through pinout. It supports 2×2 exchange switch operating at 20Gbps, and enables applications in PCI Express 4.0, USB 4.0, USB 3.1 Gen 2, Thunderbolt 4, 10G BASE-KR. When the select control input is low, Port A connects to port B, and port C connects to port D for an eight-channel differential passthough. When the select control input is high, Port A connects to port D, and port B connects to port C.

Applications

Applications up to 20 Gbps including PCIe 4.0, USB 3.2 Gen 2, 10GE, Thunderbolt 4, SAS 3.0, and SATA 3.0 Automotive

Key features

-30dB @ 4.0GHz, -19dB @ 8.06GHz, -17dB @ 10GHz
Low Insertion Loss: -1.0dB @ 4.0GHz, -1.5dB @ 8.06GHz, -2.0dB @ 10GHz
VDD Operating Range: 3.3V ± 10%
Suitable for automotive applications requiring specific change control; AEC-Q100 qualified, PPAP capable, and manufactured in IATF 16949 certified facilities
Packaging (Pb-free & Green): 30-contact, TQFN (ZL30), 2.5mm × 4.5mm
