DIODESDatasheet (PDF)
PI3USB102GZLEX
3V~5.5V 1GHz 4Ω 2 2:1 TQFN-10(1.3x1.6) Analog Switches - Special Purpose RoHS
TQFN-10(1.3x1.6)ROHS CompliantActive
USB 2.0 High-Speed (480 Mbps) Switch with 5V Protection
- Manufacturer
- DIODES
- Manufacturer part #
- PI3USB102GZLEX
- Store part #
- C155356
- Package / case
- TQFN-10(1.3x1.6)
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
8,172 in stock
#C155356
Stock & price checked 4 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹56.12 | ₹56.12 |
| 10+ | ₹44.81 | ₹448.10 |
| 30+ | ₹39.81 | ₹1,194.30 |
| 100+ | ₹33.72 | ₹3,372.00 |
| 500+ | ₹31.12 | ₹15,560.00 |
| 1,000+ | ₹29.37 | ₹29,370.00 |
1 × ₹56.12
₹56.12
excl. GST
₹66.22 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,500 per reel
PI3USB102GZLEX
₹56.12 for 1 + GST
Specifications
- Turn-on time
- 50ns
- Turn-off time
- 11ns
- Voltage - Supply
- 3V~5.5V
- -3dB Bandwidth
- 1GHz
- Ron
- 4Ω
- Number of Channels
- 2
- Propagation Delay (tpd)
- 250ps
- Switch Circuit
- 2:1
- Operating Temperature
- -40℃~+85℃
- Features
- Fault protection;Bidirectional analog channel
- Con
- 6pF
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.1 g
Overview
The PI3USB102G is a single differential channel 2:1 multiplexer/ demultiplexer USB 2.0 Switch. A propagation delay of 250ps, resulting from its low channel resistance and I/O capacitance. PI3USB102G is bidirectional and offers very little attenuation of high- speed signals. It is designed for low bit- to- bit skew, high channel- to- channel noise isolation and is compatible with various standards, such as High Speed USB 2.0 (480 Mb/s). The PI3USB102G offers over voltage protection for the Y+/Y- pins as per the USB 2.0 specification. With the chip powered on or off if Y+/Y- pins are shorted to VBUS (5V ± 5%) M+/M- and D+/D- outputs are clamped to provide voltage protection for downstream devices. The PI3USB102G has a better Y+/Y- power- off leakage current with the voltage range of 0V to 5V versus 0V to 3.3V for the PI3USB102E.
Applications
- Routes signals for USB 2.0
- PC, Notebooks and Hand - held devices
Key features
- USB 2.0 compliant (high speed, full speed, and low speed)
- RON 4.0Ω typical @ VDD = 3.0V
- Channel On Capacitance: 6.0pF
- Wide - 3dB Bandwidth: 1.000MHz
- Low bit- to- bit skew
- Low Crosstalk: - 29B @ 480 Mbps
- Off Isolation: - 28dB @ 480 Mbps
- Near- Zero propagation delay: 250ps
- Support 1.8 - V logic on control pins
- VDD Operating Range: 3.0V to 5.5V
- ESD: 8kV HBM on Y+/Y- pins per JESD22 standard
- Y+/Y- pins have over- voltage protection and can tolerate a short to VBUS
- Totally Lead - Free & Fully RoHS Compliant
- Halogen and Antimony Free. "Green" Device
- Packaging (Pb - free & Green): 10 - contact TQFN, 1.3mm × 1.6mm × 0.75mm (ZL10)
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | NX3DV42GU10X#C2151046NXP · X-QFN-10(1.3x1.6) | NXP | X-QFN-10(1.3x1.6) | 32 | ₹111.01 · 32 in stock | View |
