PNTK3139PT5G
P-Channel 20V 0.9A 100mW Surface Mount SOT-723
SOT-723RoHSActive
MOSFET P-CH 20V 0.9A SOT-723
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- PNTK3139PT5G
- Store part #
- C2912538
- Package / case
- SOT-723
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,560 in stock
#C2912538
Stock & price checked 13 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹6.73 | ₹67.30 |
| 100+ | ₹5.41 | ₹541.00 |
| 300+ | ₹4.75 | ₹1,425.00 |
| 1,000+ | ₹4.26 | ₹4,260.00 |
| 5,000+ | ₹3.40 | ₹17,000.00 |
| 8,000+ | ₹3.20 | ₹25,600.00 |
10 × ₹6.73
₹67.30
excl. GST
₹79.41 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 8,000 per reel
PNTK3139PT5G
₹67.30 for 10 + GST
Specifications
- Output Capacitance(Coss)
- 25pF
- Ciss-Input Capacitance
- 170pF
- Pd - Power Dissipation
- 100mW
- Drain to Source Voltage
- 20V
- Current - Continuous Drain(Id)
- 900mA
- Reverse Transfer Capacitance (Crss)
- 15pF
- RDS(on)
- 520mΩ@4.5V
- Number
- 1 P-Channel
- Vgs
- ±12V
- Gate Threshold Voltage (Vgs(th))
- 1.1V
- Type
- P-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 8,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.011 g
Overview
Applications
- Load/Power Switching
- Interfacing Switching
- Battery Management for Ultra Small Portable Electronics
- Logic Level Shift
Key features
- Lead-free product certified
- Surface mount package
- P-channel switch with low on-resistance (RDS(on))
- Operable at low logic-level gate drive
- Gate ESD protection
- Complementary to PNTK3139PT5G or TPM2030-3
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | PRZM002P02T2L#C2912537TECH PUBLIC · SOT-723 | TECH PUBLIC | SOT-723 | 14,520 | ₹4.27 · 14,520 in stock | View |
 | PCJ3139K#C2912539TECH PUBLIC · SOT-723 | TECH PUBLIC | SOT-723 | 8,490 | ₹5.79 · 8,490 in stock | View |
 | TPNTK3139PT1G#C558623TECH PUBLIC · SOT-723 | TECH PUBLIC | SOT-723 | 11,180 | ₹5.21 · 11,180 in stock | View |
