NexperiaDatasheet (PDF)
PSMN4R1-30YLC,115
67W 30V 92A 4.35mΩ@10V 1 N-channel N-Channel SOT-669 Single FETs, MOSFETs RoHS
SOT-669ROHS3 CompliantActive
- Manufacturer
- Nexperia
- Manufacturer part #
- PSMN4R1-30YLC,115
- Store part #
- C553290
- Package / case
- SOT-669
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
500 in stock
#C553290
Stock & price checked 8 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹140.97 | ₹140.97 |
| 10+ | ₹116.42 | ₹1,164.20 |
| 30+ | ₹103.17 | ₹3,095.10 |
| 100+ | ₹87.97 | ₹8,797.00 |
| 500+ | ₹81.23 | ₹40,615.00 |
| 1,500+ | ₹78.19 | ₹1,17,285.00 |
1 × ₹140.97
₹140.97
excl. GST
₹166.34 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 1,500 per reel
PSMN4R1-30YLC,115
₹140.97 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 316pF
- Ciss-Input Capacitance
- 1.502nF
- Pd - Power Dissipation
- 67W
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 30V
- Current - Continuous Drain(Id)
- 92A
- Reverse Transfer Capacitance (Crss)
- 106pF
- RDS(on)
- 4.35mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 23nC@10V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 1.95V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 1,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.135 g
Overview
Logic level enhancement mode N-channel MOSFET in LFPAK package. This product is designed and qualified for use in a wide range of industrial, communications, and domestic equipment.
Applications
- DC-DC Converter
- Load Switch
- Power "OR" Operation
- Server Power Supply
- Synchronous Rectifier
Key features
- High-reliability Power SO8 package, operable at 175°C
- Low parasitic inductance and resistance
- NextPower super-junction technology, optimized for 4.5V gate drive
- Ultra-low QG, QGD, and QOSS for high system efficiency at both heavy and light loads
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | BUK9Y4R4-40E,115#C550047Nexperia · SOT-669 | Nexperia | SOT-669 | 39 | ₹239.08 · 39 in stock | View |
 | BUK7Y7R2-60EX#C549928Nexperia · SOT-669 | Nexperia | SOT-669 | 16 | ₹160.32 · 16 in stock | View |
 | BUK9Y3R5-40E#C478247Nexperia · SOT-669 | Nexperia | SOT-669 | 2,865 | ₹79.22 · 2,865 in stock | View |
 | PSMN1R7-30YL,115#C553235Nexperia · SOT-669 | Nexperia | SOT-669 | 39 | ₹368.40 · 39 in stock | View |
 | PSMN2R5-30YL,115#C553256Nexperia · SOT-669 | Nexperia | SOT-669 | 99 | ₹255.42 · 99 in stock | View |
