JSMSEMIDatasheet (PDF)
PTVS12VS1UR,115-JSM
19.9V 20.1A 400W@10/1000us 14.7V Unidirectional 12V SOD-123 TVS Diodes RoHS
SOD-123ROHS CompliantActive
- Manufacturer
- JSMSEMI
- Manufacturer part #
- PTVS12VS1UR,115-JSM
- Store part #
- C53114026
- Package / case
- SOD-123
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,900 in stock
#C53114026
Stock & price checked 10 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹6.85 | ₹68.50 |
| 100+ | ₹5.46 | ₹546.00 |
| 300+ | ₹4.76 | ₹1,428.00 |
| 3,000+ | ₹4.23 | ₹12,690.00 |
| 6,000+ | ₹3.82 | ₹22,920.00 |
| 9,000+ | ₹3.61 | ₹32,490.00 |
10 × ₹6.85
₹68.50
excl. GST
₹80.83 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
PTVS12VS1UR,115-JSM
₹68.50 for 10 + GST
Specifications
- Clamping Voltage
- 19.9V
- Operating Temperature
- -55℃~+150℃
- Peak Pulse Current (Ipp)
- 20.1A
- Peak Pulse Power Dissipation (Ppp)
- 400W@10/1000us
- Number of Channels
- 1
- Voltage - Breakdown
- 14.7V
- type
- TVS
- Polarity
- Unidirectional
- Reverse Leakage Current (Ir)
- 2.5uA
- Reverse Stand-Off Voltage (Vrwm)
- 12V
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.034 g
Overview
Applications
- Personal Digital Assistants (PDA)
- Mobile phones and accessories
- Portable devices
- Portable instruments
- Handheld devices and laptops
- Digital cameras
Key features
- Surface mount application, optimized board space.
- Low-profile package.
- Excellent clamping capability.
- Compliant with IEC61000-4-2 ESD 30kV air discharge, 30kV contact discharge.
- Protects one I/O line.
- Lead-free, RoHS compliant.
- Halogen-free compliant.
