RT6253BHGJ6F
580kHz Step-down type Adjustable 765mV~7V 3A TSOT-23-6 Voltage Regulators - DC DC Switching Regulators RoHS
TSOT-23-6ROHS3 CompliantActive
3A Synchronous Buck DC-DC Converter
- Manufacturer
- RICHTEK
- Manufacturer part #
- RT6253BHGJ6F
- Store part #
- C2976605
- Package / case
- TSOT-23-6
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
34,730 in stock
#C2976605
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹27.78 | ₹138.90 |
| 50+ | ₹22.19 | ₹1,109.50 |
| 150+ | ₹19.79 | ₹2,968.50 |
| 500+ | ₹16.80 | ₹8,400.00 |
| 3,000+ | ₹13.44 | ₹40,320.00 |
| 6,000+ | ₹12.65 | ₹75,900.00 |
5 × ₹27.78
₹138.90
excl. GST
₹163.90 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
RT6253BHGJ6F
₹138.90 for 5 + GST
Specifications
- Operating Temperature
- -40℃~+125℃
- Frequency - Switching
- 580kHz
- Function
- Step-down type
- Number of Outputs
- 1
- Features
- Cycle-by-cycle current limiting;Hiccup current limiting;Light load efficient mode;Overcurrent Protection
- Output Type
- Adjustable
- Topology
- Buck
- Operating Voltage
- 4.5V~17V
- Switch tube (built-in/external)
- Built-in
- Output Voltage
- 765mV~7V
- Output Current
- 3A
- Quiescent Current
- 280uA
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.056 g
Overview
The RT6253A/B is a simple, easy-to-use, 3A synchronous step-down DC-DC converter with an input supply voltage range of 4.5V to 17V. The device possesses an accurate reference voltage and integrates low RDS(ON) power MOSFETs to achieve high efficiency. The RT6253A/B adopts Advanced Constant On-Time (ACOT®) control architecture to provide an ultrafast transient response with few external components and to operate in nearly constant switching frequency over the line, load, and output voltage range. The RT6253A operates in automatic PSM that maintains high efficiency during light load operation. The RT6253B operates in Forced PWM that helps meet tight voltage regulation accuracy requirements. The RT6253A/B senses both FETs current for a robust over-current protection (OCP). The device features cycle-by-cycle current limit protection to prevent the device from the catastrophic damage in output short circuit, over-current or inductor saturation conditions. A built-in soft-start function prevents inrush current during start-up. The device also includes input under-voltage lockout, output under-voltage protection, and overtemperature protection (OTP) to provide safe and smooth operation in all operating conditions.
Applications
- Set-Top Boxes
- LCD TVs
- Home Networking Devices
- Surveillance
- General Purpose
Key features
- Integrated 95mΩ and 50mΩ FETs
- Continuous Current:
- TSOT-23-6 (FC): 3A
- SOT-563 (FC): 2.5A
- Input Supply Voltage Range: 4.5V to 17V
- Output Voltage Range: 0.765V to 7V
- Advanced Constant On-Time (ACOT®) Control:
- Ultrafast Transient Response
- Optimized for Low-ESR Ceramic Output Capacitors
- High Accuracy Feedback Reference Voltage: ±1%
- Optional for Operation Modes:
- RT6253A: Power Saving Mode (PSM)
- RT6253B: Forced PWM Mode
- Fixed Switching Frequency: 580kHz
- Enable Control and Fixed Soft-Start with typ. 1ms
- Safe Start-Up from Pre-biased Output
- Input Under-Voltage Lockout (UVLO)
- Protection Function:
- Output Under-Voltage Protection (UVP) with Hiccup Mode
- High- / Low-side MOSFET OCP and OTP Function
- RoHS Compliant and Halogen Free
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | RT6253AHGJ6F#C2988423RICHTEK · TSOT-23-6 | RICHTEK | TSOT-23-6 | 907 | ₹34.66 · 907 in stock | View |
 | TPS563201DDCR#C116592TI · SOT-23-THIN-6 | TI | SOT-23-THIN-6 | 1,09,220 | ₹8.69 · 1,09,220 in stock | View |
 | TPS563201DDCT#C2070819TI · TSOT-23-6 | TI | TSOT-23-6 | 1,695 | ₹14.86 · 1,695 in stock | View |
 | TPS563208DDCR#C468250TI · TSOT-23-6 | TI | TSOT-23-6 | 1,09,835 | ₹20.92 · 1,09,835 in stock | View |
 | KP523208ALGA#C5124015Kiwi Instruments · TSOT-23-6 | Kiwi Instruments | TSOT-23-6 | 1,710 | ₹22.50 · 1,710 in stock | View |
