ROHMDatasheet (PDF)
RZE002P02TL
P-Channel 20V 200mA 150mW Surface Mount SC-75(SOT-416)
SC-75(SOT-416)ROHS CompliantActive
MOSFET P-CH 20V 200mA SC-75(SOT-416)
- Manufacturer
- ROHM
- Manufacturer part #
- RZE002P02TL
- Store part #
- C123069
- Package / case
- SC-75(SOT-416)
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
50 in stock
#C123069
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹7.75 | ₹77.50 |
| 100+ | ₹6.05 | ₹605.00 |
| 300+ | ₹5.20 | ₹1,560.00 |
| 3,000+ | ₹4.55 | ₹13,650.00 |
| 6,000+ | ₹4.04 | ₹24,240.00 |
| 9,000+ | ₹3.78 | ₹34,020.00 |
10 × ₹7.75
₹77.50
excl. GST
₹91.45 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
RZE002P02TL
₹77.50 for 10 + GST
Specifications
- Output Capacitance(Coss)
- 10pF
- Ciss-Input Capacitance
- 115pF
- Pd - Power Dissipation
- 150mW
- Drain to Source Voltage
- 20V
- Current - Continuous Drain(Id)
- 200mA
- Reverse Transfer Capacitance (Crss)
- 6pF
- RDS(on)
- 9.6Ω@1.2V
- Number
- 1 P-Channel
- Gate Charge(Qg)
- 1.4nC@10V
- Vgs
- ±10V
- Gate Threshold Voltage (Vgs(th))
- 1V
- Type
- P-Channel
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.024 g
Overview
Applications
- Switching
Key features
- High speed switching.
- Small package (EMT3).
- 1.2V drive.
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | NTA4151PT1G#C54876onsemi · SC-75(SOT-416) | onsemi | SC-75(SOT-416) | 7,510 | ₹6.46 · 7,510 in stock | View |
 | RE1C002ZPTL#C509960ROHM · SOT-416F | ROHM | SOT-416F | 5,750 | ₹7.22 · 5,750 in stock | View |
 | SI2301T-TWGMC#C49438147TWGMC · SOT-523 | TWGMC | SOT-523 | 1,040 | ₹4.09 · 1,040 in stock | View |
 | TW3139KT#C49438149TWGMC · SOT-523 | TWGMC | SOT-523 | 4,380 | ₹3.14 · 4,380 in stock | View |
 | RZE002P02TL-TP#C51939596TECH PUBLIC · SOT-523 | TECH PUBLIC | SOT-523 | 2,880 | ₹5.09 · 2,880 in stock | View |
