VISHAYDatasheet (PDF)
S5G-E3/57T
Diode 1 Independent 400V 5A Surface Mount DO-214AB(SMC)
DO-214AB(SMC)ROHS CompliantActive
DIODE STANDARD 400V 5A DO-214AB(SMC)
- Manufacturer
- VISHAY
- Manufacturer part #
- S5G-E3/57T
- Store part #
- C142622
- Package / case
- DO-214AB(SMC)
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
440 in stock
#C142622
Stock & price checked 8 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹24.93 | ₹124.65 |
| 50+ | ₹19.79 | ₹989.50 |
| 150+ | ₹17.58 | ₹2,637.00 |
| 850+ | ₹14.84 | ₹12,614.00 |
| 2,550+ | ₹13.61 | ₹34,705.50 |
| 5,100+ | ₹12.89 | ₹65,739.00 |
5 × ₹24.93
₹124.65
excl. GST
₹147.09 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 850 per reel
S5G-E3/57T
₹124.65 for 5 + GST
Specifications
- Operating Junction Temperature Range
- -55℃~+150℃
- Diode Configuration
- 1 Independent
- Voltage - DC Reverse (Vr) (Max)
- 400V
- Voltage - Forward(Vf@If)
- 1.15V@5A
- Reverse Leakage Current (Ir)
- 10uA@400V
- Non-Repetitive Peak Forward Surge Current
- 100A
- Current - Rectified
- 5A
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 850 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.36 g
Overview
Applications
- For use in general purpose rectification of power supplies, inverters, converters and freewheeling diodes for consumer, automotive and telecommunication.
Key features
- Low profile package Available
- Ideal for automated placement
- Glass passivated pellet chip junction
- Low forward voltage drop
- Low leakage current
- High forward surge capability
- Meets MSL level 1, per J-STD-020, LF maximum peak of 260 ℃
- AEC-Q101 qualified available - Automotive ordering code: base P/NHE3 or P/NHM3
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | S5GC-13-F#C211400DIODES · SMC(DO-214AB) | DIODES | SMC(DO-214AB) | 870 | ₹37.39 · 870 in stock | View |
 | S5MHE3_A/I#C17343199VISHAY · DO-214AB(SMC) | VISHAY | DO-214AB(SMC) | 500 | ₹97.94 · 500 in stock | View |
 | S5MS-E3/9AT#C17598338VISHAY · DO-214AB(SMC) | VISHAY | DO-214AB(SMC) | 1,115 | ₹26.79 · 1,115 in stock | View |
 | S5G#C18548242DOWO · SMC | DOWO | SMC | 2,120 | ₹4.86 · 2,120 in stock | View |
| S5K#C34693482Taiwan Semiconductor · DO-214AB | Taiwan Semiconductor | DO-214AB | 100 | ₹188.94 · 100 in stock | View | |
