JSMSEMIDatasheet (PDF)
SHYG016N10NS1TA
100V 370A Surface Mount TOLL-8
TOLL-8ROHS CompliantActive
MOSFET 100V 370A TOLL-8
- Manufacturer
- JSMSEMI
- Manufacturer part #
- SHYG016N10NS1TA
- Store part #
- C49206902
- Package / case
- TOLL-8
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,357 in stock
#C49206902
Stock & price checked 8 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹143.36 | ₹143.36 |
| 10+ | ₹119.86 | ₹1,198.60 |
| 30+ | ₹107.03 | ₹3,210.90 |
| 100+ | ₹92.45 | ₹9,245.00 |
| 500+ | ₹85.28 | ₹42,640.00 |
| 1,000+ | ₹82.22 | ₹82,220.00 |
1 × ₹143.36
₹143.36
excl. GST
₹169.16 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,000 per reel
SHYG016N10NS1TA
₹143.36 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 100V
- Current - Continuous Drain(Id)
- 370A
- Output Capacitance(Coss)
- 1.93nF
- Ciss-Input Capacitance
- 15.8nF
- Pd - Power Dissipation
- 431W
- Reverse Transfer Capacitance (Crss)
- 75pF
- RDS(on)
- 1.2mΩ@10V
- Number
- 1 N-channel
- Gate Threshold Voltage (Vgs(th))
- 3V
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 1.092 g
Overview
- Split-gate trench MOSFET technology - Superior thermal dissipation package - High-density cell design for reduced RDS(ON) - Moisture Sensitivity Level 1 - Epoxy meets UL 94 V-0 flammability rating - Halogen-free
Applications
- Power switching applications
- Uninterruptible power supplies
- DC-DC converters
- Motor drivers
Key features
- 100% EAS tested
- 100% ∇VDS tested
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SHYG015N10NS1TA#C49206901JSMSEMI · TOLL-8 | JSMSEMI | TOLL-8 | 141 | ₹218.14 · 141 in stock | View |
 | SNCEP023N10LL#C49206904JSMSEMI · TOLL-8 | JSMSEMI | TOLL-8 | 1,463 | ₹188.59 · 1,463 in stock | View |
 | JSM015N10LG#C49206905JSMSEMI · TOLL-8 | JSMSEMI | TOLL-8 | 192 | ₹157.33 · 192 in stock | View |
