HXY MOSFETDatasheet (PDF)
SI4894BDY-T1-E3-HXY
30V 10A 2.2W 9mΩ@10V 1 N-channel N-Channel SOP-8 Single FETs, MOSFETs
SOP-8RoHSActive
- Manufacturer
- HXY MOSFET
- Manufacturer part #
- SI4894BDY-T1-E3-HXY
- Store part #
- C54582801
- Package / case
- SOP-8
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
48 in stock
#C54582801
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹134.80 | ₹134.80 |
| 10+ | ₹110.68 | ₹1,106.80 |
| 30+ | ₹98.63 | ₹2,958.90 |
| 100+ | ₹86.56 | ₹8,656.00 |
| 500+ | ₹71.07 | ₹35,535.00 |
| 1,000+ | ₹67.20 | ₹67,200.00 |
1 × ₹134.80
₹134.80
excl. GST
₹159.06 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SI4894BDY-T1-E3-HXY
₹134.80 for 1 + GST
Specifications
- Configuration
- Standalone
- Drain to Source Voltage
- 30V
- Output Capacitance(Coss)
- 110pF
- Current - Continuous Drain(Id)
- 10A
- Ciss-Input Capacitance
- 580pF
- Pd - Power Dissipation
- 2.2W
- Reverse Transfer Capacitance (Crss)
- 94pF
- RDS(on)
- 9mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 8nC@4.5V
- Gate Threshold Voltage (Vgs(th))
- 1.4V
- Type
- N-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.146 g
Overview
The SI4894BDY-T1-E3 employs advanced trench technology to deliver excellent RDS(ON), low gate charge, and operation at gate voltages as low as 4.5V. The device is suitable for battery protection or other switching applications. Package: SOP-8.
Applications
- Battery protection
- Load switch
- Uninterruptible power supply
- N-channel MOSFET
Key features
- Drain-source voltage (VDS) = 30V, drain current (ID) = 10A
- On-resistance (RDS(ON)) < 12mΩ at gate-source voltage (VGS) = 10V
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | AOSP36326C#C54582795HXY MOSFET · SOP-8 | HXY MOSFET | SOP-8 | 40 | ₹26.17 · 40 in stock | View |
 | SI4894BDY-T1-GE3-HXY#C54582802HXY MOSFET · SOP-8 | HXY MOSFET | SOP-8 | 48 | ₹77.74 · 48 in stock | View |
 | NTMS4917NR2G-HXY#C54582806HXY MOSFET · SOP-8 | HXY MOSFET | SOP-8 | 40 | ₹40.35 · 40 in stock | View |
 | AO4566#C54582809HXY MOSFET · SOP-8 | HXY MOSFET | SOP-8 | 40 | ₹40.35 · 40 in stock | View |
 | AO4420A#C54582810HXY MOSFET · SOP-8 | HXY MOSFET | SOP-8 | 30 | ₹40.35 · 30 in stock | View |
