SIA440DJ-T1-GE3
N-Channel 40V 8.6A 3.5W Surface Mount PowerPAK-SC-70-6L
PowerPAK-SC-70-6LROHS3 CompliantActive
MOSFET N-CH 40V 8.6A PowerPAK-SC-70-6L
- Manufacturer
- VISHAY
- Manufacturer part #
- SIA440DJ-T1-GE3
- Store part #
- C727349
- Package / case
- PowerPAK-SC-70-6L
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,192 in stock
#C727349
Stock & price checked 12 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹74.56 | ₹74.56 |
| 10+ | ₹59.09 | ₹590.90 |
| 30+ | ₹52.55 | ₹1,576.50 |
| 100+ | ₹44.27 | ₹4,427.00 |
| 500+ | ₹40.55 | ₹20,275.00 |
| 1,000+ | ₹38.38 | ₹38,380.00 |
1 × ₹74.56
₹74.56
excl. GST
₹87.98 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SIA440DJ-T1-GE3
₹74.56 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 87pF
- Ciss-Input Capacitance
- 700pF
- Pd - Power Dissipation
- 3.5W
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 40V
- Current - Continuous Drain(Id)
- 8.6A
- Reverse Transfer Capacitance (Crss)
- 40pF
- RDS(on)
- 26mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 6.9nC@4.5V
- Vgs
- ±12V
- Gate Threshold Voltage (Vgs(th))
- 1.4V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.038 g
Overview
Applications
- Portable Devices such as Tablet PCs and Mobile Computing
- DC/DC Converter
- Boost Converter
- Load Switch
- Power Management
- LED Backlighting
Key features
- TrenchFET Power MOSFET
- 100 % Rg and UIS Tested
