VISHAYDatasheet (PDF)
SIS128LDN-T1-GE3
N-Channel 80V 33.7A 39W Surface Mount PowerPAK1212-8
PowerPAK1212-8ROHS3 CompliantActive
MOSFET N-CH 80V 33.7A PowerPAK1212-8
- Manufacturer
- VISHAY
- Manufacturer part #
- SIS128LDN-T1-GE3
- Store part #
- C3279448
- Package / case
- PowerPAK1212-8
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,520 in stock
#C3279448
Stock & price checked 12 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹161.05 | ₹161.05 |
| 10+ | ₹132.83 | ₹1,328.30 |
| 30+ | ₹117.43 | ₹3,522.90 |
| 100+ | ₹99.85 | ₹9,985.00 |
| 500+ | ₹92.03 | ₹46,015.00 |
| 1,000+ | ₹88.56 | ₹88,560.00 |
1 × ₹161.05
₹161.05
excl. GST
₹190.04 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SIS128LDN-T1-GE3
₹161.05 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 80V
- Output Capacitance(Coss)
- 127pF
- Current - Continuous Drain(Id)
- 33.7A
- Ciss-Input Capacitance
- 1.25nF
- Pd - Power Dissipation
- 39W
- Reverse Transfer Capacitance (Crss)
- 7.8pF
- RDS(on)
- 15.6mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 14.5nC@4.5V
- Gate Threshold Voltage (Vgs(th))
- 2.5V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.06 g
Overview
Applications
- Synchronous rectification
- Primary side switch
- DC/DC converter
- Motor drive control
- Load switch
Key features
- TrenchFET Gen IV power MOSFET
- Very low RDS×Qg figure-of-merit (FOM)
- Tuned for the lowest RDS×Qoss FOM
- 100 % Rg and UIS tested
- RoHS COMPLIANT HALOGEN FREE
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | BMQ100N38#C42432421BORN · DFN3333-8L | BORN | DFN3333-8L | 2,105 | ₹33.45 · 2,105 in stock | View |
 | NTTFS012N10MDTAG#C5208924onsemi · WDFN-8(3.3x3.3) | onsemi | WDFN-8(3.3x3.3) | 8 | ₹158.20 · 8 in stock | View |
 | SQS182ELNW-T1_GE3#C20346181VISHAY · PowerPAK1212-8SLW | VISHAY | PowerPAK1212-8SLW | 73 | ₹99.46 · 73 in stock | View |
 | CMSC100N10L#C55185728Cmos · DFN-8(3.3x3.3) | Cmos | DFN-8(3.3x3.3) | 215 | ₹34.52 · 215 in stock | View |
 | STTFS015N10MCL#C5205722onsemi · WDFN-8(3.3x3.3) | onsemi | WDFN-8(3.3x3.3) | 18 | ₹223.32 · 18 in stock | View |
