VISHAYDatasheet (PDF)
SM8S15AHE3_A/I
24.4VC Clamp 270A@10/1000us Ipp TVS DIODE DO-218AB
DO-218ABROHS3 CompliantActive
TVS DIODE 15VWM 24.4VC DO-218AB
- Manufacturer
- VISHAY
- Manufacturer part #
- SM8S15AHE3_A/I
- Store part #
- C1975894
- Package / case
- DO-218AB
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
8 in stock
#C1975894
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹811.18 | ₹811.18 |
| 10+ | ₹720.48 | ₹7,204.80 |
| 30+ | ₹666.74 | ₹20,002.20 |
| 100+ | ₹612.15 | ₹61,215.00 |
| 750+ | ₹587.00 | ₹4,40,250.00 |
| 1,500+ | ₹575.61 | ₹8,63,415.00 |
1 × ₹811.18
₹811.18
excl. GST
₹957.19 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 750 per reel
SM8S15AHE3_A/I
₹811.18 for 1 + GST
Specifications
- Clamping Voltage
- 24.4V
- Operating Temperature
- -55℃~+175℃
- Peak Pulse Current (Ipp)
- 270A@10/1000us
- Peak Pulse Power Dissipation (Ppp)
- 6.6kW@10/1000us
- Number of Channels
- 1
- Voltage - Breakdown
- 18.5V
- type
- TVS
- Polarity
- Unidirectional
- Reverse Leakage Current (Ir)
- 10uA
- Reverse Stand-Off Voltage (Vrwm)
- 15V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 750 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 2.64 g
Overview
Applications
- Use in sensitive electronics protection against voltage transients induced by inductive load switching and lighting, especially for automotive load dump protection application.
Key features
- Junction passivation optimized design passivated anisotropic rectifier technology
- T_J = 175 °C capability suitable for high reliability e3 and automotive requirement RoHS
- Available in uni-directional polarity only COMPLIANT
- Low leakage current
- Low forward voltage drop
- High surge capability
- Meets ISO7637-2 surge specification (varied by test condition)
- Meets MSL level 1, per J-STD-020, LF maximum peak of 245 °C
- AEC-Q101 qualified
