SMAJ22A-Q
46.2VC Clamp 56.5A@8/20us Ipp TVS DIODE SMA(DO-214AC)
- Manufacturer
- BOURNS
- Manufacturer part #
- SMAJ22A-Q
- Store part #
- C1974945
- Package / case
- SMA(DO-214AC)
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
79 in stock
#C1974945
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹55.04 | ₹55.04 |
| 10+ | ₹54.18 | ₹541.80 |
| 30+ | ₹53.53 | ₹1,605.90 |
| 100+ | ₹52.88 | ₹5,288.00 |
1 × ₹55.04
₹55.04
excl. GST
₹64.95 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
SMAJ22A-Q
₹55.04 for 1 + GST
Specifications
- Clamping Voltage
- 46.2V
- Operating Temperature
- -55℃~+150℃
- Peak Pulse Current (Ipp)
- 56.5A@8/20us
- Peak Pulse Power Dissipation (Ppp)
- 400W
- Number of Channels
- 1
- Voltage - Breakdown
- 26.9V
- type
- TVS
- Polarity
- Unidirectional
- Reverse Leakage Current (Ir)
- 1uA
- Reverse Stand-Off Voltage (Vrwm)
- 22V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.118 g
Overview
Bourns offers Transient Voltage Suppressor Diodes for surge and ESD protection applications, in compact chip package DO-214AC (SMA) size format. The Transient Voltage Suppressor series offers a choice of Working Peak Reverse Voltage from 5 V up to 220 V. Typical fast response times are less than 1.0 picosecond from 0 V to Breakdown Voltage.
Applications
- Protection of power buses
- Protection of I/O interfaces
- Overvoltage transient protection
- Telecom, computer, industrial and consumer electronics applications
Key features
- Surface Mount SMA package
- Standoff Voltage: 5 to 220 volts
- Power Dissipation: 400 watts
- RoHS compliant
- AEC-Q101 compliant
