SMBJ6.0A-Q
12VC Clamp 326.5A@8/20us Ipp TVS DIODE SMB(DO-214AA)
TVS DIODE 6VWM 12VC SMB(DO-214AA)
- Manufacturer
- BOURNS
- Manufacturer part #
- SMBJ6.0A-Q
- Store part #
- C1518355
- Package / case
- SMB(DO-214AA)
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
120 in stock
#C1518355
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹48.98 | ₹244.90 |
| 50+ | ₹38.88 | ₹1,944.00 |
| 150+ | ₹34.56 | ₹5,184.00 |
| 500+ | ₹29.16 | ₹14,580.00 |
| 3,000+ | ₹26.76 | ₹80,280.00 |
| 6,000+ | ₹25.31 | ₹1,51,860.00 |
5 × ₹48.98
₹244.90
excl. GST
₹288.98 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SMBJ6.0A-Q
₹244.90 for 5 + GST
Specifications
- Clamping Voltage
- 12V
- Operating Temperature
- -55℃~+150℃
- Peak Pulse Current (Ipp)
- 326.5A@8/20us
- Peak Pulse Power Dissipation (Ppp)
- 600W
- Number of Channels
- 1
- Voltage - Breakdown
- 7V
- type
- TVS
- Polarity
- Unidirectional
- Reverse Leakage Current (Ir)
- 800uA
- Reverse Stand-Off Voltage (Vrwm)
- 6V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.119 g
Overview
Bourns offers Transient Voltage Suppressor Diodes for surge and ESD protection applications, in compact chip package DO-214AA (SMB) size format. The Transient Voltage Suppressor series offers a choice of Working Peak Reverse Voltage from 5 V up to 220 V. Typical fast response times are less than 1.0 picosecond from 0 to Breakdown Voltage.
Applications
- Protection of power buses
- Protection of I/O interfaces
- Overvoltage transient protection
- Entertainment applications
- Comfort applications
- Telecom, computer, industrial and consumer electronics applications
Key features
- Surface Mount SMB package
- Standoff Voltage: 5 to 220 volts
- Power Dissipation: 600 watts
- RoHS compliant
- AEC-Q101 compliant
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SMBJ6.0A#C284027DOWO · SMB(DO-214AA) | DOWO | SMB(DO-214AA) | 5,840 | ₹5.19 · 5,840 in stock | View |
 | SMBJ6.0A#C2925477Liown · SMB(DO-214AA) | Liown | SMB(DO-214AA) | 3,110 | ₹6.43 · 3,110 in stock | View |
 | SMBJ6.0A#C2987966RUILON · DO-214AA(SMB) | RUILON | DO-214AA(SMB) | 5,655 | ₹10.58 · 5,655 in stock | View |
 | SMBJ6.0A#C3001967UMW · SMB(DO-214AA) | UMW | SMB(DO-214AA) | 14,175 | ₹4.99 · 14,175 in stock | View |
 | SMBJ6.0A#C3019957Slkor · SMB(DO-214AA) | Slkor | SMB(DO-214AA) | 730 | ₹5.41 · 730 in stock | View |
