SMBJ8.5CA-Q
18.7VC Clamp 208.5A@8/20us Ipp TVS DIODE DO-214AA
- Manufacturer
- BOURNS
- Manufacturer part #
- SMBJ8.5CA-Q
- Store part #
- C1518406
- Package / case
- DO-214AA
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
30 in stock
#C1518406
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹73.73 | ₹73.73 |
| 10+ | ₹72.66 | ₹726.60 |
| 30+ | ₹71.80 | ₹2,154.00 |
| 100+ | ₹70.94 | ₹7,094.00 |
1 × ₹73.73
₹73.73
excl. GST
₹87.00 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SMBJ8.5CA-Q
₹73.73 for 1 + GST
Specifications
- Clamping Voltage
- 18.7V
- Operating Temperature
- -55℃~+150℃
- Peak Pulse Current (Ipp)
- 208.5A@8/20us
- Peak Pulse Power Dissipation (Ppp)
- 600W
- Number of Channels
- 1
- Voltage - Breakdown
- 11.1V
- type
- TVS
- Polarity
- Bidirectional
- Reverse Leakage Current (Ir)
- 20uA
- Reverse Stand-Off Voltage (Vrwm)
- 8.5V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.19 g
Overview
Bourns offers Transient Voltage Suppressor Diodes for surge and ESD protection applications, in compact chip package DO-214AA (SMB) size format. The Transient Voltage Suppressor series offers a choice of Working Peak Reverse Voltage from 5 V up to 220 V. Typical fast response times are less than 1.0 picosecond from 0 to Breakdown Voltage.
Applications
- Protection of power buses
- Protection of I/O interfaces
- Overvoltage transient protection
- Entertainment applications
- Comfort applications
- Telecom, computer, industrial and consumer electronics applications
Key features
- Surface Mount SMB package
- Standoff Voltage: 5 to 220 volts
- Power Dissipation: 600 watts
- RoHS compliant
- AEC-Q101 compliant
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
| SMBJ9.0CA-E3/5B#C1845207VISHAY · DO-214AA(SMBJ) | VISHAY | DO-214AA(SMBJ) | 2,435 | ₹43.76 · 2,435 in stock | View | |
 | SMBJ9.0CA#C20623782Brightking · SMB(DO-214AA) | Brightking | SMB(DO-214AA) | 1,730 | ₹7.94 · 1,730 in stock | View |
 | SMBJ9.0CA#C49066941R+O · SMB(DO-214AA) | R+O | SMB(DO-214AA) | 840 | ₹6.13 · 840 in stock | View |
 | SMBJ9.0CA#C49242993PDW · SMB(DO-214AA) | PDW | SMB(DO-214AA) | 960 | ₹4.21 · 960 in stock | View |
 | SMBJ9.0CA#C50087826JDTfuse · SMB | JDTfuse | SMB | 3,000 | ₹7.32 · 3,000 in stock | View |
