SMCJ54CA-Q
107.1VC Clamp 91A@8/20us Ipp TVS DIODE SMC(DO-214AB)
- Manufacturer
- BOURNS
- Manufacturer part #
- SMCJ54CA-Q
- Store part #
- C1977245
- Package / case
- SMC(DO-214AB)
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
63 in stock
#C1977245
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹137.35 | ₹137.35 |
| 10+ | ₹135.42 | ₹1,354.20 |
| 30+ | ₹134.13 | ₹4,023.90 |
| 100+ | ₹132.84 | ₹13,284.00 |
1 × ₹137.35
₹137.35
excl. GST
₹162.07 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SMCJ54CA-Q
₹137.35 for 1 + GST
Specifications
- Clamping Voltage
- 107.1V
- Operating Temperature
- -55℃~+150℃
- Peak Pulse Current (Ipp)
- 91A@8/20us
- Peak Pulse Power Dissipation (Ppp)
- 1.5kW
- Number of Channels
- 1
- Voltage - Breakdown
- 66.3V
- type
- TVS
- Polarity
- Bidirectional
- Reverse Leakage Current (Ir)
- 1uA
- Reverse Stand-Off Voltage (Vrwm)
- 54V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.332 g
Overview
Bourns offers Transient Voltage Suppressor Diodes for surge and ESD protection applications, in compact chip package DO-214AB (SMC) size format. The Transient Voltage Suppressor series offers a choice of Working Peak Reverse Voltage from 5 V up to 120 V. Typical fast response times are less than 1.0 picosecond from 0 V to Breakdown Voltage. Chip Diodes conform to JEDEC standards, are easy to handle with standard pick and place equipment and their flat configuration minimizes roll away.
Applications
- Protection of power buses
- Protection of I/O interfaces
- Overvoltage transient protection
- Entertainment applications
- Comfort applications
- Telecom, computer, industrial and consumer electronics applications
Key features
- Surface Mount SMC package
- Standoff Voltage: 5 to 120 volts
- Power Dissipation: 1500 watts
- RoHS compliant
- AEC-Q101 compliant
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SMCJ54CA#C20883231OTW · SMC(DO-214AB) | OTW | SMC(DO-214AB) | 3,000 | ₹9.47 · 3,000 in stock | View |
 | SMCJ54CA#C22371767JUXING · SMC | JUXING | SMC | 3,000 | ₹21.60 · 3,000 in stock | View |
 | SMCJ54CA#C41411761R+O · SMC(DO-214AB) | R+O | SMC(DO-214AB) | 12,495 | ₹19.85 · 12,495 in stock | View |
 | SMCJ54CA#C438219Jingdao Microelectronics · SMC | Jingdao Microelectronics | SMC | 3,065 | ₹14.25 · 3,065 in stock | View |
 | SMCJ54CA-13-F#C135179DIODES · SMC | DIODES | SMC | 90 | ₹83.67 · 90 in stock | View |
