SMDJ90CA
146VC Clamp 20.5A Ipp TVS DIODE DO-214AB(SMC)
TVS DIODE 90VWM 146VC DO-214AB(SMC)
- Manufacturer
- Yint
- Manufacturer part #
- SMDJ90CA
- Store part #
- C5449734
- Package / case
- DO-214AB(SMC)
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
30 in stock
#C5449734
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹28.56 | ₹142.80 |
| 50+ | ₹22.42 | ₹1,121.00 |
| 150+ | ₹19.79 | ₹2,968.50 |
| 500+ | ₹16.52 | ₹8,260.00 |
| 2,500+ | ₹15.06 | ₹37,650.00 |
| 5,000+ | ₹14.18 | ₹70,900.00 |
5 × ₹28.56
₹142.80
excl. GST
₹168.50 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
SMDJ90CA
₹142.80 for 5 + GST
Specifications
- Clamping Voltage
- 146V
- Operating Temperature
- -55℃~+150℃
- Peak Pulse Current (Ipp)
- 20.5A
- Peak Pulse Power Dissipation (Ppp)
- 3kW@10/1000us
- Number of Channels
- 1
- Voltage - Breakdown
- 100V
- type
- TVS
- Polarity
- Bidirectional
- Reverse Leakage Current (Ir)
- 2uA
- Reverse Stand-Off Voltage (Vrwm)
- 90V
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Sold out at source
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.415 g
Overview
The SMD series is designed to protect voltage-sensitive components from high-voltage, high-energy transients. They feature excellent clamping capability, high surge capacity, low Zener impedance, and fast response time. With a unique design offering high cost-effectiveness and reliability, the SMD series is ideal for use in communication systems, automotive, CNC, process control, medical equipment, commercial machinery, power supplies, and many other industrial/consumer applications.
Applications
- Transient Voltage Suppression (TVS) devices are ideal for protecting I/O interfaces, Vcc buses, and other vulnerable circuits in telecommunications, computing, industrial, and consumer electronics applications.
Key features
- Package: DO-214AB/SMC
- Surface mount application, optimized PCB space utilization.
- 3000 W peak pulse power capability under 10/1000 μs waveform.
- Typical failure mode: short circuit due to voltage or current exceeding rated values.
- Leads: tin-plated, solderable per MIL-STD-750 Method 2026.
- Compliant with IEC61000-4-2 (ESD): air discharge ±30 kV, contact discharge ±30 kV.
