VISHAY

SMP24A-M3/84A

38.9VC Clamp 10.3A@10/1000us Ipp TVS DIODE DO-220AA(SMP)

DO-220AA(SMP)ROHS3 CompliantActive

TVS DIODE 24VWM 38.9VC DO-220AA(SMP)

Manufacturer: VISHAY
Manufacturer part #: SMP24A-M3/84A
Store part #: C1974757
Package / case: DO-220AA(SMP)
Category: TVS Diodes
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

4,430 in stock

#C1974757

Stock & price checked 11 days ago

Quantity	Unit price	Pack price
5+	₹17.46	₹87.30
50+	₹15.14	₹757.00
150+	₹14.14	₹2,121.00
500+	₹12.90	₹6,450.00
3,000+	₹12.34	₹37,020.00
6,000+	₹12.01	₹72,060.00

Quantity (min 5, multiples of 5)

5 × ₹17.46

₹87.30

excl. GST

₹103.01 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 3,000 per reel

SMP24A-M3/84A

₹87.30 for 5 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Clamping Voltage: 38.9V
Operating Temperature: -55℃~+150℃
Peak Pulse Current (Ipp): 10.3A@10/1000us
Peak Pulse Power Dissipation (Ppp): 400W@10/1000us
Number of Channels: 1
Voltage - Breakdown: 29.5V
type: TVS
Polarity: Unidirectional
Reverse Leakage Current (Ir): 1uA
Reverse Stand-Off Voltage (Vrwm): 24V

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.057 g

Overview

Applications

Use in sensitive electronics protection against voltage transients induced by inductive load switching and lighting on ICs, MOSFET, signal lines of sensor units for consumer, computer, industrial, and telecommunication.

Key features

Very low profile - typical height of 1.0 mm
Ideal for automated placement RoHS
Available in uni-directional COMPLIANT HALOGEN
400 W peak pulse power capability with a FREE 10/1000 μs waveform
Excellent clamping capability
Very fast response time
Low incremental surge resistance
Meets MSL level 1, per J-STD-020, LF maximum peak of 260 °C
