SN6501DBVR
SOT-23-5 Power Management - Specialized RoHS
PopularSOT-23-5ROHS3 CompliantActive
Transformer Driver for Isolated Power Supplies
- Manufacturer
- TI
- Manufacturer part #
- SN6501DBVR
- Store part #
- C49451
- Package / case
- SOT-23-5
- Category
- Power Management - Specialized
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
16,809 in stock
#C49451
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹71.07 | ₹71.07 |
| 10+ | ₹56.52 | ₹565.20 |
| 30+ | ₹50.21 | ₹1,506.30 |
| 100+ | ₹42.39 | ₹4,239.00 |
| 500+ | ₹34.99 | ₹17,495.00 |
| 1,000+ | ₹32.82 | ₹32,820.00 |
1 × ₹71.07
₹71.07
excl. GST
₹83.86 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SN6501DBVR
₹71.07 for 1 + GST
Specifications
- Operating Temperature
- -40℃~+125℃
- Current - Continuous Drain(Id)
- 350mA
- RDS(on)
- 600mΩ
- Drain to Source Voltage
- 11V
- Quiescent Current
- 300uA
- Voltage - Supply
- 3V~5.5V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.055 g
Overview
The SN6501 is a monolithic oscillator/power-driver, specifically designed for small form factor, isolated power supplies in isolated interface applications. The device drives a low-profile, center-tapped transformer primary from a 3.3-V or 5-V DC power supply. The secondary can be wound to provide any isolated voltage based on transformer turns ratio. The SN6501 consists of an oscillator followed by a gate drive circuit that provides the complementary output signals to drive the ground referenced Nchannel power switches. The internal logic ensures break-before-make action between the two switches. The SN6501 is available in a small SOT-23 (5) package, and is specified for operation at temperatures from -40°C to 125°C.
Applications
- Isolated Interface Power Supply for CAN, RS-485, RS-422, RS-232, SPI, I2C, Low-Power LAN
- Industrial Automation
- Process Control
- Medical Equipment
Key features
- Push-Pull Driver for Small Transformers
- Single 3.3-V or 5-V Supply
- High Primary-side Current Drive:
- 5-V Supply: 350 mA (Max)
- 3.3-V Supply: 150 mA (Max)
- Low Ripple on Rectified Output Permits Small Output Capacitors
- Small 5-Pin SOT-23 Package
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SN6501DBVT#C2650141TI · SOT-23-5 | TI | SOT-23-5 | 651 | ₹81.27 · 651 in stock | View |
 | MX6501T#C19078227Wuxi Maxinmicro · SOT-23-5L | Wuxi Maxinmicro | SOT-23-5L | 6,525 | ₹25.36 · 6,525 in stock | View |
 | COS6501#C30212523COSINE · SOT-23-5 | COSINE | SOT-23-5 | 725 | ₹37.30 · 725 in stock | View |
 | VPS6501#C7470607VPSC · SOT23-5 | VPSC | SOT23-5 | 4,195 | ₹47.05 · 4,195 in stock | View |
 | VPS8504C#C2986361VPSC · SOT-23-5 | VPSC | SOT-23-5 | 2,673 | ₹99.52 · 2,673 in stock | View |
