TECH PUBLIC

SP3051-04HTG

20VC Clamp 30A@8/20us 60A@8/20us Ipp SOT-23-6

SOT-23-6RoHSActive

5VWM 20VC SOT-23-6

Manufacturer: TECH PUBLIC
Manufacturer part #: SP3051-04HTG
Store part #: C42379178
Package / case: SOT-23-6
Category: TVS Diodes
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

3,410 in stock

#C42379178

Stock & price checked 12 days ago

Quantity	Unit price	Pack price
5+	₹27.29	₹136.45
50+	₹24.05	₹1,202.50
150+	₹22.66	₹3,399.00
500+	₹20.93	₹10,465.00
3,000+	₹20.16	₹60,480.00
6,000+	₹19.70	₹1,18,200.00

Quantity (min 5, multiples of 5)

5 × ₹27.29

₹136.45

excl. GST

₹161.01 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 3,000 per reel

SP3051-04HTG

₹136.45 for 5 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Clamping Voltage: 20V
Operating Temperature: -55℃~+125℃
Peak Pulse Current (Ipp): 30A@8/20us;60A@8/20us
Peak Pulse Power Dissipation (Ppp): 600W@8/20us
Voltage - Breakdown: 6V
Reverse Leakage Current (Ir): 1uA
Reverse Stand-Off Voltage (Vrwm): 5V

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.038 g

Overview

Applications

T1/E1 Line Cards
T3/E3 and DS3 Interfaces
Low Voltage Interfaces
ISDN Interfaces

Key features

Low operating voltage: 5V
Ultra low capacitance: 1.5pF typical (I/O to I/O)
Ultra low leakage: nA level
Low clamping voltage
IEC 61000-4-2 (ESD) immunity test Air discharge: ±30kV Contact discharge: ±30kV
IEC61000-4-4 (EFT) 40A (5/50ns)
IEC61000-4-5(Lightning):30A(8/20μs)
These are Pb-Free Devices
Response Time is Typically < 1 ns

Alternatives

Similar parts — check the datasheet before substituting.

Part		Manufacturer	Package	Stock	Price from (excl. GST)	Action
	TPESD05M4S6#C42379173TECH PUBLIC · SOT-23-6	TECH PUBLIC	SOT-23-6	500	₹72.69 · 500 in stock	View
