SQ3457EV-T1_GE3
P-Channel 30V 3.9A 1.7W Surface Mount TSOP-6
TSOP-6ROHS CompliantActive
MOSFET P-CH 30V 3.9A TSOP-6
- Manufacturer
- VISHAY
- Manufacturer part #
- SQ3457EV-T1_GE3
- Store part #
- C727378
- Package / case
- TSOP-6
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
13 in stock
#C727378
Stock & price checked 4 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹92.15 | ₹92.15 |
| 10+ | ₹74.76 | ₹747.60 |
| 30+ | ₹66.07 | ₹1,982.10 |
| 100+ | ₹57.38 | ₹5,738.00 |
| 500+ | ₹52.15 | ₹26,075.00 |
| 1,000+ | ₹49.55 | ₹49,550.00 |
1 × ₹92.15
₹92.15
excl. GST
₹108.74 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SQ3457EV-T1_GE3
₹92.15 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 140pF
- Ciss-Input Capacitance
- 705pF
- Pd - Power Dissipation
- 1.7W
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 30V
- Current - Continuous Drain(Id)
- 3.9A
- Reverse Transfer Capacitance (Crss)
- 120pF
- RDS(on)
- 35mΩ@10V;72mΩ@4.5V
- Number
- 1 P-Channel
- Gate Charge(Qg)
- 21nC@10V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 1.5V
- Type
- P-Channel
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.029 g
Overview
Key features
- Halogen-free According to IEC 61249-2-2 Definition
- TrenchFET Power MOSFET
- AEC-Q101 Qualified
- 100 % Rg and UIS Tested
- Compliant to RoHS Directive 2002/95/EC
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | TPSI3457CDV#C5246404TECH PUBLIC · SOT-23-6 | TECH PUBLIC | SOT-23-6 | 2,965 | ₹15.65 · 2,965 in stock | View |
 | TPDMP3056LDM#C5246407TECH PUBLIC · SOT-23-6 | TECH PUBLIC | SOT-23-6 | 80 | ₹9.41 · 80 in stock | View |
 | TPFDC654P#C5246409TECH PUBLIC · SOT-23-6 | TECH PUBLIC | SOT-23-6 | 2,795 | ₹15.65 · 2,795 in stock | View |
 | CPH6350-TL-W#C890563onsemi · SC-74-6 | onsemi | SC-74-6 | 5 | ₹39.68 · 5 in stock | View |
 | SQ3427AEEV-T1_GE3#C144943VISHAY · TSOP-6 | VISHAY | TSOP-6 | 22,118 | ₹76.63 · 22,118 in stock | View |
