SQ4917EY-VB
P-Channel 60V 8A 5W Surface Mount SO-8
SO-8RoHSSold out at source
MOSFET P-CH 60V 8A SO-8
- Manufacturer
- VBsemi Elec
- Manufacturer part #
- SQ4917EY-VB
- Store part #
- C725193
- Package / case
- SO-8
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
7 in stock
#C725193
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹98.74 | ₹98.74 |
| 10+ | ₹80.24 | ₹802.40 |
| 30+ | ₹71.01 | ₹2,130.30 |
| 100+ | ₹61.76 | ₹6,176.00 |
| 500+ | ₹50.21 | ₹25,105.00 |
| 1,000+ | ₹47.27 | ₹47,270.00 |
1 × ₹98.74
₹98.74
excl. GST
₹116.51 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 4,000 per reel
SQ4917EY-VB
₹98.74 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 334pF
- Ciss-Input Capacitance
- 1.91nF
- Pd - Power Dissipation
- 5W
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 60V
- Current - Continuous Drain(Id)
- 8A
- Reverse Transfer Capacitance (Crss)
- 142pF
- RDS(on)
- 50mΩ@10V;60mΩ@4.5V
- Number
- 1 P-Channel
- Gate Charge(Qg)
- 65nC@10V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 1V
- Type
- P-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Sold out at source
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.135 g
Overview
Key features
- TrenchFET power MOSFET
- 100 % Rg and UIS tested
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | NDS9407-VB#C692948VBsemi Elec · SO-8 | VBsemi Elec | SO-8 | 6 | ₹97.47 · 6 in stock | View |
 | SI9407AEY-T1-E3-VB#C19626688VBsemi Elec · SO-8 | VBsemi Elec | SO-8 | 25 | ₹85.92 · 25 in stock | View |
 | BSO613SPV G-VB#C2680874VBsemi Elec · SO-8 | VBsemi Elec | SO-8 | 8 | ₹84.66 · 8 in stock | View |
 | SQ9407EY-T1-GE3-VB#C5878854VBsemi Elec · SO-8 | VBsemi Elec | SO-8 | 53 | ₹85.21 · 53 in stock | View |
 | UT4421G-S08-R-VB#C20417740VBsemi Elec · SO-8 | VBsemi Elec | SO-8 | 51 | ₹97.13 · 51 in stock | View |
