VISHAYDatasheet (PDF)
SQD40061EL_GE3
P-Channel 40V 100A 35W Surface Mount TO-252
TO-252ROHS3 CompliantActive
MOSFET P-CH 40V 100A TO-252
- Manufacturer
- VISHAY
- Manufacturer part #
- SQD40061EL_GE3
- Store part #
- C3281460
- Package / case
- TO-252
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
15 in stock
#C3281460
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹290.32 | ₹290.32 |
| 10+ | ₹245.22 | ₹2,452.20 |
| 30+ | ₹217.04 | ₹6,511.20 |
| 100+ | ₹187.99 | ₹18,799.00 |
| 500+ | ₹174.98 | ₹87,490.00 |
| 1,000+ | ₹169.34 | ₹1,69,340.00 |
1 × ₹290.32
₹290.32
excl. GST
₹342.58 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,000 per reel
SQD40061EL_GE3
₹290.32 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 40V
- Output Capacitance(Coss)
- 1.1nF
- Current - Continuous Drain(Id)
- 100A
- Ciss-Input Capacitance
- 14.5nF
- Pd - Power Dissipation
- 35W
- Reverse Transfer Capacitance (Crss)
- 1nF
- RDS(on)
- 7.1mΩ@4.5V
- Number
- 1 P-Channel
- Gate Charge(Qg)
- 280nC@10V
- Gate Threshold Voltage (Vgs(th))
- 2.5V
- Type
- P-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.593 g
Overview
Key features
- TrenchFET power MOSFET
- Package with low thermal resistance
- 100 % Rg and UIS tested
- AEC - Q101 qualified
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | HSU4119#C28314523HUASHUO · TO-252 | HUASHUO | TO-252 | 2,594 | ₹119.69 · 2,594 in stock | View |
 | SP40P04TH#C41355036Siliup · TO-252 | Siliup | TO-252 | 4,553 | ₹65.05 · 4,553 in stock | View |
| LWS6008A4#C20630416Lewa Micro · TO-252 | Lewa Micro | TO-252 | 1,695 | ₹128.00 · 1,695 in stock | View | |
 | HSU100P04#C2987712HUASHUO · TO-252-2 | HUASHUO | TO-252-2 | 2,246 | ₹123.83 · 2,246 in stock | View |
 | CI100P04#C42391834Tokmas · TO-252 | Tokmas | TO-252 | 315 | ₹40.58 · 315 in stock | View |
