VISHAYDatasheet (PDF)
SQJ403EP-T1_GE3
30V 30A 68W 8.5mΩ@10V 1 P-Channel P-Channel PowerPAK-SO-8 Single FETs, MOSFETs RoHS
PowerPAK-SO-8ROHS3 CompliantActive
Automotive P-Channel MOSFET, Current: 30A, Voltage: 30V
- Manufacturer
- VISHAY
- Manufacturer part #
- SQJ403EP-T1_GE3
- Store part #
- C3289491
- Package / case
- PowerPAK-SO-8
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
37 in stock
#C3289491
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹547.03 | ₹547.03 |
| 10+ | ₹469.63 | ₹4,696.30 |
| 30+ | ₹423.44 | ₹12,703.20 |
| 100+ | ₹376.83 | ₹37,683.00 |
| 500+ | ₹355.15 | ₹1,77,575.00 |
| 1,000+ | ₹345.61 | ₹3,45,610.00 |
1 × ₹547.03
₹547.03
excl. GST
₹645.50 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SQJ403EP-T1_GE3
₹547.03 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 30V
- Output Capacitance(Coss)
- 1nF
- Current - Continuous Drain(Id)
- 30A
- Ciss-Input Capacitance
- 4.5nF
- Pd - Power Dissipation
- 68W
- Reverse Transfer Capacitance (Crss)
- 770pF
- RDS(on)
- 8.5mΩ@10V
- Number
- 1 P-Channel
- Gate Charge(Qg)
- 109nC@10V
- Gate Threshold Voltage (Vgs(th))
- 2.5V
- Type
- P-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.232 g
Overview
Key features
- Trench power MOSFET
- AEC-Q101 qualified
- 100% gate resistance (Rg) and unclamped inductive switching (UIS) tested
- RoHS compliant and halogen-free
- P-channel
