Silergy

SY50213WFAC

2.1A 60kHz~70kHz 1.1W 6V~14V 800V Flyback SO-8 AC DC Converters, Offline Switchers

SO-8RoHSActive

Flyback Regulator With Primary Side CV/CC Control

Manufacturer: Silergy
Manufacturer part #: SY50213WFAC
Store part #: C5632094
Package / case: SO-8
Category: AC DC Converters, Offline Switchers
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

11,855 in stock

#C5632094

Stock & price checked 4 days ago

Quantity	Unit price	Pack price
5+	₹41.98	₹209.90
50+	₹33.46	₹1,673.00
150+	₹29.81	₹4,471.50
500+	₹22.69	₹11,345.00
2,500+	₹20.67	₹51,675.00
5,000+	₹19.45	₹97,250.00

Quantity (min 5, multiples of 5)

5 × ₹41.98

₹209.90

excl. GST

₹247.68 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 2,500 per reel

SY50213WFAC

₹209.90 for 5 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Operating Temperature: -40℃~+125℃
Output Current: 2.1A
Frequency - Switching: 60kHz~70kHz
Pd - Power Dissipation: 1.1W
Voltage - Supply: 6V~14V
Voltage - Breakdown: 800V
Topology: Flyback
Features: Constant Current Mode (CC);Constant Voltage (CV);Over Voltage Protection;Short Circuit Protection;Overtemperature protection (OTP);Over Current Protection
Feedback System: Primary-side feedback
Working Mode: QR;PWM Modulation;PFM Modulation

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Moisture sensitivity: MSL 3 (168 hours)
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 2,500 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.147 g

Overview

SY50213W is a single stage Flyback regulator targeting at Constant Current/Constant Voltage CC/CV) applications. It integrates a 800V bipolar NPN transistor in a compact SO8 package to minimize the size. Both the output current and voltage are sensed on the primary side, eliminating the opto- isolator and the secondary side feedback circuitry, and minimizing the overall system cost. SY50213W adopts the quasi- resonant operation and the adaptive PwM/PFM control to achieve the highest average efficiency and the best EMI performance. The no- load switching frequency can be as low as 500Hz, minimizing the no- load power loss. SY50213W has programmable cable compensation to provide a better load regulation for the output voltage at the cable terminals. SY50213W provides reliable protections including VIN Over Voltage Protection, Short Circuit Protection (SCP), Over Temperature Protection (OTP), Output voltage OVP protection (OVP), VSEN/ISEN pin short protection, VSEN pin upper divider resistor disconnect protection.
