onsemiDatasheet (PDF)
SZNUP4114HMR6T1G
10V 12A@8/20us 6.5V 5.5V TSOP-6 TVS Diodes RoHS
TSOP-6ROHS3 CompliantActive
ESD DIODE 5.5VWM 10VC TSOP-6
- Manufacturer
- onsemi
- Manufacturer part #
- SZNUP4114HMR6T1G
- Store part #
- C463673
- Package / case
- TSOP-6
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
86 in stock
#C463673
Stock & price checked 10 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹102.94 | ₹102.94 |
| 10+ | ₹100.65 | ₹1,006.50 |
| 30+ | ₹99.20 | ₹2,976.00 |
| 100+ | ₹97.73 | ₹9,773.00 |
1 × ₹102.94
₹102.94
excl. GST
₹121.47 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SZNUP4114HMR6T1G
₹102.94 for 1 + GST
Specifications
- Clamping Voltage
- 10V
- Operating Temperature
- -40℃~+125℃
- Peak Pulse Current (Ipp)
- 12A@8/20us
- Voltage - Breakdown
- 6.5V
- type
- ESD
- Reverse Leakage Current (Ir)
- 1uA
- Reverse Stand-Off Voltage (Vrwm)
- 5.5V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.019 g
Overview
The NUP4114 ESD protection diode array is designed to protect high speed data lines from ESD. Ultra−low capacitance and high level of ESD protection make these devices well suited for use in USB 2.0 high speed applications.
Applications
- LVDS
- USB 2.0 High Speed Data Line and Power Line Protection
- Digital Video Interface (DVI) and HDMI
- Gigabit Ethernet
- Monitors and Flat Panel Displays
- Notebook Computers
- communications systems
- computers
- computer peripherals
- high speed I/O data lines
Key features
- Low Clamping Voltage
- Low Capacitance (<0.6 pF Typical, I/O to GND)
- Low Leakage
- Response Time is Typically <1.0 ns
- IEC61000−4−2 Level 4 ESD Protection
- SZ Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC−Q101 Qualified and PPAP Capable
- These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS Compliant
