TIDatasheet (PDF)
TL082QDRQ1
3mV 13V/us 86dB 20nA 1.4mA 3MHz SOIC-8 Instrumentation, Op Amps, Buffer Amps RoHS
SOIC-8ROHS3 CompliantActive
JFET-INPUT OPERATIONAL AMPLIFIER
- Manufacturer
- TI
- Manufacturer part #
- TL082QDRQ1
- Store part #
- C79302
- Package / case
- SOIC-8
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,005 in stock
#C79302
Stock & price checked 15 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹55.80 | ₹55.80 |
| 10+ | ₹43.42 | ₹434.20 |
| 30+ | ₹38.00 | ₹1,140.00 |
| 100+ | ₹31.49 | ₹3,149.00 |
| 500+ | ₹28.44 | ₹14,220.00 |
| 1,000+ | ₹26.71 | ₹26,710.00 |
1 × ₹55.80
₹55.80
excl. GST
₹65.84 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
TL082QDRQ1
₹55.80 for 1 + GST
Specifications
- Vos - Input Offset Voltage
- 3mV
- Slew Rate
- 13V/us
- Input Offset Current(Ios)
- 100pA
- Operating Temperature
- -40℃~+125℃
- Common Mode Rejection Ratio(CMRR)
- 86dB
- Ib - Input Bias Current
- 20nA
- Input Offset Voltage Drift(Vos TC)
- 18uV/℃
- Quiescent Current
- 1.4mA
- Gain Bandwidth Product
- 3MHz
- Features
- Latch-up suppression
- Input Voltage Noise Density
- 3nV/√Hz@1kHz
- Dual Supply
- -15V~15V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.175 g
Overview
The TL082 JFET-input operational amplifier incorporates well-matched, high-voltage JFET and bipolar transistors in a monolithic integrated circuit. The device features high slew rates, low input bias and offset currents, and low offset-voltage temperature coefficient. The I-suffix device is characterized for operation from -40°C to 85°C. The Q.-suffix device is characterized for operation from -40°C to 125°C.
Key features
- Qualified for Automotive Applications
- Low Power Consumption Wide Common-Mode and Differential Voltage Ranges
- Low Input Bias and Offset Currents
- Low Total Harmonic Distortion: 0.003% Typ
- High Input Impedance: JFET-Input Stage
- Latchup-Free Operation
- High Slew Rate: 13 V/μs Typ
- Common-Mode Input Voltage Range Includes VCC+
