TLC3702IDR
2 18uA 1.2mV SOIC-8 Comparators RoHS
Push-Pull CMOS Output Drives Capacitive Loads Without Pullup Resistor
- Manufacturer
- TI
- Manufacturer part #
- TLC3702IDR
- Store part #
- C93244
- Package / case
- SOIC-8
- Category
- Comparators
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
10,481 in stock
#C93244
Stock & price checked 4 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹89.95 | ₹89.95 |
| 10+ | ₹72.57 | ₹725.70 |
| 30+ | ₹63.87 | ₹1,916.10 |
| 100+ | ₹55.18 | ₹5,518.00 |
| 500+ | ₹49.97 | ₹24,985.00 |
| 1,000+ | ₹47.36 | ₹47,360.00 |
1 × ₹89.95
₹89.95
excl. GST
₹106.14 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
TLC3702IDR
₹89.95 for 1 + GST
Specifications
- Number of Channels
- 2
- Input Offset Current(Ios)
- 1pA
- Output Mode
- CMOS
- Operating Temperature
- -40℃~+85℃
- Features
- ESD protection
- Ib - Input Bias Current
- 5pA
- Output Type
- Push-pull
- Propagation Delay(tpd)
- 2.7us
- Common Mode Rejection Ratio(CMRR)
- 84dB
- Quiescent Current(Iq)
- 18uA
- Vos - Input Offset Voltage
- 1.2mV
- Maximum Power Supply Range (Vdd-Vss)
- 18V
- Single Supply
- 3V~16V
- Response Time (tr)
- 125ns
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.173 g
Overview
The TLC3702 consists of two independent micropower voltage comparators designed to operate from a single supply and be compatible with modern HCMOS logic systems. They are functionally similar to the LM339 but use one-twentieth of the power for similar response times. The push-pull CMOS output stage drives capacitive loads directly without a power-consuming pullup resistor to achieve the stated response time. Eliminating the pullup resistor not only reduces power dissipation, but also saves board space and component cost. The output stage is also fully compatible with TTL requirements. Texas Instruments LinCMOS process offers superior analog performance to standard CMOS processes. Along with the standard CMOS advantages of low power without sacrificing speed, high input impedance, and low bias currents, the LinCMOS process offers extremely stable input offset voltages with large differential input voltages. This characteristic makes it possible to build reliable CMOS comparators. The TLC3702C is characterized for operation over the commercial temperature range of 0℃ to 70℃. The TLC3702I is characterized for operation over the extended industrial temperature range of -40℃ to 85℃. The TLC3702M is characterized for operation over the full temperature range of -55℃ to 125℃.
Key features
- Push-Pull CMOS Output Drives Capacitive Loads Without Pullup Resistor, Io = ±8 mA
- Very Low Power... 100 μA Typ at 5 V
- Fast Response Time... tPLH = 2.7 μs Typ With 5-mV Overdrive
- Single-Supply Operation... 3 V to 16 V TLC3702M... 4 V to 16 V
- On-Chip ESD Protection
