TPD4E05U06DQAR
15VC Clamp 5A Ipp ESD DIODE DFN2510-10L
ESD DIODE 3.3VWM 15VC DFN2510-10L
- Manufacturer
- HXY MOSFET
- Manufacturer part #
- TPD4E05U06DQAR
- Store part #
- C5337182
- Package / case
- DFN2510-10L
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
285 in stock
#C5337182
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹10.77 | ₹53.85 |
| 50+ | ₹8.57 | ₹428.50 |
| 150+ | ₹7.47 | ₹1,120.50 |
| 500+ | ₹6.64 | ₹3,320.00 |
| 3,000+ | ₹5.72 | ₹17,160.00 |
| 6,000+ | ₹5.38 | ₹32,280.00 |
5 × ₹10.77
₹53.85
excl. GST
₹63.54 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
TPD4E05U06DQAR
₹53.85 for 5 + GST
Specifications
- Clamping Voltage
- 15V
- Operating Temperature
- -40℃~+125℃
- Peak Pulse Current (Ipp)
- 5A
- Peak Pulse Power Dissipation (Ppp)
- 150W
- Number of Channels
- Four channels
- Voltage - Breakdown
- 6V
- type
- ESD
- Reverse Leakage Current (Ir)
- 1uA
- Polarity
- Unidirectional
- Reverse Stand-Off Voltage (Vrwm)
- 3.3V
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.029 g
Overview
TPD4E05U06DQAR is a 4-channel ultra-low capacitance rail-clamp ESD protection diode array. Each channel consists of a pair of diodes that steer positive or negative ESD current to the positive or negative rail. A Zener diode is integrated in the array between the positive and negative supply rails. In a typical application, the negative rail pin (designated as GND) is connected to system ground. Positive ESD current is steered to ground through the ESD diodes and Zener diode, and positive ESD voltage is clamped to the Zener voltage.
Key features
- Solid-state silicon avalanche technology
- Low working and clamping voltage
- Up to four I/O line protection
- Ultra-low capacitance: typical 0.5pF (I/O to I/O)
- Low leakage
- Low operating voltage: 3.3V
- Feed-through design
- DFN2510 - 10L (USON - 10(1x2.5))
