TX4314
360kHz boost converter 230mA 4.8V~5.1V SOT-23-6 Voltage Regulators - DC DC Switching Regulators RoHS
SOT-23-6ROHS CompliantActive
Low-noise, regulated charge pump DC/DC converter
- Manufacturer
- XDS
- Manufacturer part #
- TX4314
- Store part #
- C329270
- Package / case
- SOT-23-6
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
5,075 in stock
#C329270
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹15.02 | ₹75.10 |
| 50+ | ₹11.77 | ₹588.50 |
| 150+ | ₹10.16 | ₹1,524.00 |
| 500+ | ₹8.94 | ₹4,470.00 |
| 3,000+ | ₹7.63 | ₹22,890.00 |
| 6,000+ | ₹7.16 | ₹42,960.00 |
5 × ₹15.02
₹75.10
excl. GST
₹88.62 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
TX4314
₹75.10 for 5 + GST
Specifications
- Operating Temperature
- -40℃~+85℃
- Frequency - Switching
- 360kHz
- Function
- boost converter
- Features
- Low ripple / low noise architecture;Output short-circuit protection;Load disconnect;Low-power standby
- Operating Voltage
- 2.7V~4.5V
- Output Current
- 230mA
- Output Voltage
- 4.8V~5.1V
- Quiescent Current
- 170uA
- Energy Efficiency
- 78%
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.041 g
Overview
TX4314 is a low-noise switched-capacitor voltage doubler. It generates a regulated output voltage from a 2.7V to 4.5V input. The minimal external component count (only one flying capacitor and two small bypass capacitors for VIN and VOUT) makes the device ideal for small battery-powered applications. The device features over-temperature protection and can withstand continuous short circuits from VOUT to GND. A low-current shutdown function disconnects the load from VIN, with quiescent current <1μA. The device is available in a SOT23-6 package.
Applications
- Network systems
- Medical devices
- Consumer electronics
- White LED backlighting
- Li-ion battery backup power
- Smart card reader PCMCIA local 5V supply
Key features
- Input voltage: 2.7 - 4.5V
- Fixed: 5V output
- Output current: 110mA (VIN ≥ 3V)
- 230mA (VIN ≥ 3...6V)
- Low-noise constant frequency (360kHz)
- Shutdown current <1uA
- Inductor-free
