U3502C
150kHz Step-down type Adjustable 3A ESOP-8 Voltage Regulators - DC DC Switching Regulators RoHS
ESOP-8ROHS CompliantActive
100V Input, Switching Current Limit Step-Down Converter
- Manufacturer
- UNI-SEMIC
- Manufacturer part #
- U3502C
- Store part #
- C20626024
- Package / case
- ESOP-8
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,935 in stock
#C20626024
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹49.55 | ₹247.75 |
| 50+ | ₹38.47 | ₹1,923.50 |
| 150+ | ₹33.91 | ₹5,086.50 |
| 500+ | ₹28.03 | ₹14,015.00 |
| 2,500+ | ₹26.74 | ₹66,850.00 |
| 4,000+ | ₹24.99 | ₹99,960.00 |
5 × ₹49.55
₹247.75
excl. GST
₹292.34 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 4,000 per reel
U3502C
₹247.75 for 5 + GST
Specifications
- Number of Outputs
- 1
- Frequency - Switching
- 150kHz
- Function
- Step-down type
- Features
- Overcurrent Protection;Hiccup current limiting
- Output Type
- Adjustable
- Topology
- Buck
- Switch tube (built-in/external)
- Built-in
- Output Current
- 3A
- Quiescent Current
- 700uA
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.18 g
Overview
The U3502C is a high-voltage step-down switching regulator with an integrated MOSFET. It integrates a high-side high-voltage power MOSFET with a typical current limit of 3A (IPK). Its wide input voltage range supports various buck applications, making it ideal for automotive, industrial, and lighting applications. Hysteretic voltage-mode control is adopted for fast transient response. A proprietary feedback control scheme minimizes the number of required external components. The 150KHz switching frequency helps achieve compact component size. Thermal shutdown and short-circuit protection (SCP) provide reliable, fault-tolerant operation. Low quiescent current makes the U3502C suitable for battery-powered applications. The U3502C is available in an ESOP-8 package with an exposed thermal pad.
Applications
- Scooter and e-bike control power supplies
- Solar energy systems
- Automotive system power supplies
- Industrial power supplies
- High-power LED drivers
Key features
- Integrated high-voltage startup circuit
- Integrated 5.3V reference
- Built-in 100V/135mΩ MOSFET
- Built-in bootstrap diode
- Hysteretic control: no compensation required
- 150KHz switching frequency
- PWM dimming control input for buck applications
- Short-circuit protection (SCP) for integrated high-side MOSFET
- Low quiescent current
- Thermal shutdown
- ESOP-8 package with exposed thermal pad
